Dell Part #/MPN: WLD15
DiscTech Item #: DEL-WLD15-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:14Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Interface Types: USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45, DisplayPort, SVGA, 3.5mm Headphone
Voltage: 110-240V Multi
Dell WLD15 7DCTG / 61GRY E/Port Plus Wireless Docking Station with USB 3.0 (WiGig Capable)
DP/N - 61GRY, WLD15, 452-BBUX
The Dell Wireless Docking Station (WLD15: WiGig capable)
The Dell Wireless Dock (WLD15) is the second generation WiGig docking station for Dell. It is designed based on the Tri-band Intel 17265 802.11ad wireless local area network (WLAN) and Intel WiGig 1.1 specifications.
The WLD15 has the following features:
Video connections: 1 - mini-DisplayPort (DP1.2), 1 - HDMI (1.4) and 1 - Video Graphics Array (VGA)
I/O ports: 1 - Headset Connection, 1 - Speaker out
Network port: 1 - 10/100/1000 LAN Connection
USB: 2 - front USB 3.0 ports (one with Powershare), 1 - rear USB 3.0 port, 2 - rear USB 2.0 ports
Wireless status LED:
Search/Disconnected mode: Steady Amber
Connected mode: Steady White
Pairing: Amber blinking
Firmware upgrade: White blinking
Error: Alternating White and amber
Operating system support: Windows 7, 8, 8.1,& 10
System Requirements:
Computers equipped with an Intel WiGig antenna and Intel WiGig Module (Intel® Tri-Band Wireless-AC 17265 WiGig + WLAN + BT4.0LE Wireless Card) supporting WBE protocol
Compatible Systems.
Systems that are compatible with the WLD15 WiGig wireless dock meet the following minimum hardware/software requirements:
ePort e/Port e-Port
Equipped with an Intel WiGig antenna
Equipped with an Intel 17265 Tri-Band 802.11ad WLAN module
Microsoft Windows 7, 8, 8.1 or Windows 10 (Post release)
As of May 2015, WLD15 compatible systems include:
Latitude E7250
Latitude E7450
Latitude E5450
Latitude E5550
Latitude E5250
Compatibility:
Compatible Systems.
Systems that are compatible with the WLD15 WiGig wireless dock meet the following minimum hardware/software requirements:
Equipped with an Intel WiGig antenna
Equipped with an Intel 17265 Tri-Band 802.11ad WLAN module
Microsoft Windows 7, 8, 8.1 or Windows 10 (Post release)
As of May 2015, WLD15 compatible systems include:
Latitude E7250
Latitude E7450
Latitude E5450
Latitude E5550
Latitude E5250
ePort e/Port e-Port
The WLD15 has the following features:
Video connections: 1 - mini-DisplayPort (DP1.2), 1 - HDMI (1.4) and 1 - Video Graphics Array (VGA)
I/O ports: 1 - Headset Connection, 1 - Speaker out
Network port: 1 - 10/100/1000 LAN Connection
USB: 2 - front USB 3.0 ports (one with Powershare), 1 - rear USB 3.0 port, 2 - rear USB 2.0 ports
Wireless status LED:
Search/Disconnected mode: Steady Amber
Connected mode: Steady White
Pairing: Amber blinking
Firmware upgrade: White blinking
Error: Alternating White and amber
Operating system support: Windows 7, 8, 8.1,& 10
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 7DCTG 61GRY 07DCTG 061GRY 452-BBUX
Weight: 8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
