Fujitsu MAU SCSI Hard Drive MAU3147NC

FUJITSU Part #/MPN: MAU3147NC

DiscTech Item #: FUJ-MAU3147NC-BN-OE


$209.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$209.00

Enterprise Grade

Capacity: 146GB

Speed: 15,000RPM

Interface Types: SCSI 80pin SCA-2 Hot-Swap

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 147

Average Seek Time: 3.3 / 3.8

Electrical Interface: SCSI LVD U320 - 320MBps 16-bit

On-Board Cache: 8MB

Fujitsu MAU 147GB 15K U320 80pin SCA-2 SCSI Hard Drive MAU3147NC - Brand New OEM Fujitsu MAU 147GB 15K U320 80pin SCA-2 SCSI Hard Drive MAU3147NC - Brand New OEM

Drive specification

MAU3147NC

Formatted Gbytes (512 bytes/sector)

147

Bytes per sector

512

Read/write heads

8

Data Disks

4

Areal density (Gbits/inch2 avg)

59

Spindle speed (RPM)

15,000

Internal data transfer rate (Mbytes/sec max)

147

I/O data transfer rate (Mbytes/sec max)

320

ATA data-transfer modes supported

PIO modes 0–4

Cache buffer

8 Mbytes

Height (max)

25.4 mm

Width (max)

101.6 mm

Length (max)

146.00 mm

Recording Code

32/34 MEEPRML

Head Positioning Method

Rotary VCM

Track-to-track seek time (msec typical)

0.2/.4

Average seek (msec typical)

3.3/3.8

Average seek, write (msec typical)

11

Startup current (typical) 12V (peak)

2.5 amps

Idle mode (typical) watts

11.5

MTBF

1,200,000 hours

Ambient temperature

5° to 55 °C (op.)

–40° to 70°C (nonop.)


Click here to view the manufacturer's item description/brochure

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
