FUJITSU Part #/MPN: MBA3147RC
DiscTech Item #: FUJ-MBA3147RC-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:3Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 146GB
Speed: 15,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Average Seek Time: 3.4 / 3.9
Electrical Interface: SAS-1 Serial Attached SCSI - 3.0Gbps
On-Board Cache: 16MB
Compatible Systems: Dell 10th Gen. 2950 / 6950
Toshiba / Fujitsu MBA 147GB 15K 3Gbps SAS Hard Drive MBA3147RC - Brand New
Fujitsu MBA 147GB 15K 3Gbps Serial Attached SCSI Hard Drive MBA3147RC - Brand New
Fujitsu p/n: CA06778-B200
Compatibility:
Dell PowerEdge 1950, 1955, 2900, 2950, 6950
Compaq/HP Proliant:
BL20p G4, BL460c, BL465c, BL480c, DL360 G4p, DL360 G5, DL380 G4, DL380 G5, DL385, DL385 G2, DL580 G3, DL580 G4, DL585, DL585 G2, ML350 G5, ML370 G4, ML370 G5, ML570 G3, ML570 G4
| FUNCTIONAL SPECIFICATIONS | |
|---|---|
| Formatted storage capacity | 147 GB |
| Seek time Track to Track Average Full Track | 0.2 / 0.4 ms. typ. (read/write) 3.4 / 3.9 ms. typ. (read/write) 8.0/9.0 ms. typ. (read/write) |
| Average latency time | 2.00 ms. |
| Rotational speed | 15,005 RPM |
| Interface | SAS (3Gbps) |
| Data Buffer Size | 16 MB |
| Recording code | 60/62 MEEPRML |
| Head positioning method | ROTARY VCM |
| Spindle start time | 20 seconds typical |
| Spindle stop time | 20 seconds typical |
| PHYSICAL SPECIFICATIONS | |
| Power requirement Idle (ready) | 12.8 W typ. |
| Form Factor | 3.5-inch x 1-inch high |
| Mounting screws | #6 x 32UNC |
| Height | 25.4 mm |
| Width | 101.6 mm |
| Depth | 146.0 mm |
| Weight | 0.75 kg |
| Ambient temperature Operating Non-operating | 5 to 55 degrees C -40 to 70 degrees C |
| Maximum DE surface temperature (operating) | 60 max deg. C |
| Gradient | 20 degrees C per hour |
| Relative humidity Operating Non-operating | 5 to 95 % RH (non-condensing) 5 to 95 % RH (non-condensing) |
| Maximum wet bulb | 29 degrees C (non-condensing) |
| Vibration Operating Non-operating | 0.6mm (5 to 20 Hz)/ 1.0G (20 to 300 Hz) 3.1mm (5 to 20 Hz)/ 5.0G (20 to 300Hz) |
| Shock Operating Non-operating | 65G Max (2ms) 250G Max (2ms) |
| Altitude Operating Non-operating | 3,000 metres 12,000 metres |
| Acoustic noise (at 1 metre idle) | >/=3.6 (ready) bels |
| RELIABILITY | |
| MTBF (Mean Time Between Failures) | 1,400,000 power on hours |
| Component life (years) - Design life used to calculate MTBF. NOT Warranty | 5 years |
| Unrecoverable errors | 1 per 10^15 bits read |
| Seek errors | 10 per 10^8 seeks |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: CA06778-B25000HV CA06778-B200
