Hitachi Part #/MPN: 0A36143
DiscTech Item #: HIT-0A36143-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 85 - 42
Average Seek Time: 8.2
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 32MB
Hitachi Ultrastar A7K1000 0A36143 / HUA721010KLA330 1TB 7.2K 3Gbps Enterprise SATA Hard Drive - Refurbished
Hitachi Ultrastar A7K1000 0A36143 / HUA721010KLA330 1TB / 1000GB 7,200 RPM 3.0Gbps Enterprise SATA Hard Drive - Refurbished
Ultrastar™ A7K1000
3.5-INCH ENTERPRISE HARD DISK DRIVES
World’s first terabyte hard drive for the enterprise – Ideal for high-capacity storage in enterprise and nearline environments
Highlights
- Up to 1 terabyte of capacity
- 3 Gb/s SATA for configuration flexibility
- Targeted 1.2 million hours MTBF
- Enhanced Rotational Vibration Safeguard (RVS) for robust performance in multi-drive environments
Applications/Environments
- RAID arrays
- Tiered storage
- Nearline storage
- Disk-to-disk back up
- Network Attached Storage (NAS)
- Data warehousing
Record capacity, enterprise-class reliability
The Ultrastar™ A7K1000 delivers up to one terabyte of storage capacity in a standard 3.5-inch form factor, filling a vital need for high-density storage in the enterprise. As the third generation design, based on the popular Deskstar™ E7K500, the Ultrastar A7K1000 continues to set the standard in enterprise-class reliability and performance for enterprise and nearline applications requiring high-capacity storage. With a unique 5-platter design, Hitachi has relaxed the bit densities to achieve higher reliability. The Ultrastar A7K1000 is built using the industry’s most reliable perpendicular magnetic recording (PMR) recording heads and media.
Performance targeted for the enterprise
The Ultrastar A7K1000 features a 3 Gb/s SATA interface supporting key features in the Serial-ATA specification including Native Command Queuing (NCQ), staggered spin-up and hot-swap capability. The Ultrastar A7K1000 allows for configuration scalability and with the same physical connector as Serial Attached SCSI (SAS) drives, it’s ideal for use in mixed-drive environments.
In multi-drive environments, rotational vibration, which results from the vibration of neighboring drives in a system, can degrade hard drive performance. To aid in maintaining high performance, the Ultrastar A7K1000 incorporates enhanced Rotational Vibration Safeguard (RVS) technology providing up to 50% improvement over the previous generation against performance degradation, leading the industry.
Compatibility:
This drive is compatible with any server that accepts 3.5"x1" (LFF) SATA hard drives.
| Specifications | |
|---|---|
| Model / Part Numbers | HUA721010KLA330 / 0A36143 |
| Interface | 3 Gb/s SATA |
| Capacity | 1 TB / 1000 GB |
| Recording zones | 30 |
| Data heads (physical) | 10 |
| Data disks | 5 |
| Max areal density (Gbits/sq. in.) | 148 |
| Performance | |
| Data buffer (MB) | 32 |
| Rotational speed (RPM) | 7200 |
| Latency average (ms) | 4.17 |
| Media transfer rate (Mbits/sec, max) | 1070 |
| Interface transfer rate (MB/sec, max) | 300 |
| Sustained transfer rate (MB/sec) | 84 - 42 (zone 0-29) |
| Seek time (read, typical, ms) | 8.2 |
| Reliability | |
| Error rate (non-recoverable, bits read) | 1 in 1015 |
| Start/stops (at 40˚ C) | 50,000 |
| Availability (days/week) | 24 x 7 |
| Targeted MTBF (hours) | 1,200,000 |
| Acoustics | |
| Idle (Bels) | 2.9 |
| Power | |
| Requirement | +5 VDC (+ -5%), +12 VDC (+ 20% - 8%) |
| Startup current (max. A) | 2.0 (+ 12V) & 1.2 (+ 5V) |
| Idle (W) | 9.0 |
| Power consump. efficiency index (W/GB) | 0.009 |
| Physical size | |
| z-height (mm, max) | 26.1 |
| Dimensions (width x depth, mm) | 101.6 x 147 |
| Weight (g, max) | 700 |
| Environmental (operating) | |
| Ambient temperature | 5o to 60o C |
| Shock (half-sine wave, G/2ms) | 70 |
| Vibration, random (G RMS 5 to 500 Hz) | 0.67, all axes |
| Environmental (non-operating) | |
| Ambient temperature | -40o to 70o C |
| Shock (half-sine wave, G/1ms) | 300 |
| Vibration, random (G RMS 2 to 200 Hz) | 1.04, all axes |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: HUA721010KLA330
Weight: 1.8 lb
Warranty: 1 Year DiscTech
