Hitachi 0B24532 HUS156060VLS600 SAS Hard Disk Drive

Hitachi Part #/MPN: 0B24532

DiscTech Item #: HIT-0B24532-RF-OE


$54.00
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$54.00

Enterprise Grade

Capacity: 600GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 520

Sustained Throughput: 119 to 198

Average Seek Time: 3.4

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Compatible Systems: Dell 10th Gen. 2950 / 6950

Hitach Ultrastar 15K600 600GB 15K RPM 6.0Gbps Serial SCSI / SAS Hard Drive 0B24532 / HUS156060VLS600 - Refurbished

Ultrastar™ 15K600

The all-in-one enterprise drive delivers performance and capacity in one package

Combines ultimate performance with high capacity in the same drive. The 6Gb/s Serial Attached SCSI (SAS) and 4Gb/s Fibre Channel Arbitrated Loop (FCAL) interfaces support the reliability required in the most demanding enterprise computing environments.

Hitachi Part Numbers: 0B24532 / HUS156060VLS600 / DKR2J-K60SS

For Hitachi Data Systems Storage - 520K Block Size


Compatibility:

All SAS compatible servers including:

IBM, HP Proliant, Dell PowerEdge 1900, 1950, 2900, 2950, 6900, 6950. PowerVault MD1000.

Specifications
Part Number0B24532
Model NumberHUS156060VLS600
Model NameUltrastar 15K600
Configuration
InterfaceSAS 6Gb/s
Capacity (GB)600
Data heads (physical)8 / 6 / 4
Data Disks4 / 3 / 2
Performance
Data buffer (MB)64
Rotational speed (RPM)15,000
Interface transfer rate (MB/s, max)600
Sustained transfer rate (MB/s, typical)198 to 119
Seek time (read/write, ms, typical)3.4
Reliability
Error Rate (non-recoverable, bits read)1 in 10^16
MTBF (M hours)1.6
Availability (hrs/day x days/wk)24x7
Acoustics
Idle (Bels)3.7
Power
Requirement+5 VDC (+/5%)
+12 VDC (+/5%)
Operating (W, typical)16.6
Unload idle (W)10.7
Physical size
Z-height (mm)25.8
Dimensions (width x depth, mm)101.6 x 146.2
Weight (g, max)750
Environmental (operating)
Ambient temperature5º to 55ºC
Shock (half-sine wave)30G (2ms)
Vibration1.5Gm all axes
Environmental (non-operating)
Ambient temperature-40º to 70ºC
Shock (half-sine wave)250G (2ms)
Vibration2.0G, all axes

Click here to view the manufacturer's item description/brochure

Alternate MPNs: HUS156060VLS600 DKR2J-K60SS

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
