Hitachi 5K100 13G1584 80GB 5.4K 2.5" IDE Laptop Hard Drive

(0) No Reviews Yet

Hitachi Part #/MPN: 13G1584

DiscTech Item #: HIT-13G1584-FR-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Capacity: 80GB

Speed: 5,400RPM

Interface Types: IDE ATA 2.5in IDC44M for laptop

Form Factor: 2.5inx9mm Fits Most laptops

Sector Size: 512 / 512e

Average Seek Time: 12

Electrical Interface: EIDE Ultra ATA100 100MBps

On-Board Cache: 8MB

Model number 13G1584 / HTS541080G9AT00
Model Name 5K100
Form Factor(width) 2.5-inch
Form Factor(height) 9.5 mm
Height 9.5 mm
Width 70 mm
Length 100 mm
Weight 0.102 kg
Formatted Capacity 80 Gbytes
Internal Transfer Rate (max) 493 Mbits/sec
External (I/O) Transfer Rate (max) 100 MBytes/sec
Average Seek Time, Read 12 msec typical
Average Latency 5.5 msec
Default Buffer (cache) Size 8 Mbytes
Number of Discs (physical) 2
Number of Heads (physical) 4
Startup Current (5VDC +/- 5%) 5 watts
Max Operating Shock (2-msec) 300 Gs
Max Nonoperating Shock (1-msec) 1000 Gs
Operating Temperature (max) 55 deg C
Operating Temperature (min) 5 deg C
Nonoperating Temperature (max) 65 deg C
Nonoperating Temperature (min) -40 deg C
Acoustics, Idle (sound power, typ) 2.7 Bels

Click here to view the manufacturer's item description/brochure

Alternate MPNs: HTS541080G9AT00

Weight: 1 lb

Warranty: 1 Year DiscTech

Factory Refurbished

Condition Levels Explained

The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
