Hitachi UltraStar 7K3000 0B26312 Serial SCSI / SAS Hard Disk Drives

(0) No Reviews Yet

Hitachi Part #/MPN: 0B26312

DiscTech Item #: HIT-0B26312-RF-OE


$115.00
$115.00

Enterprise Grade

Capacity: 2TB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 166

Average Seek Time: 7.6

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Hitachi UltraStar 7K3000 0B26312 / HUS723020ALS640 2TB / 2000GB 7.2K 6.0Gbps Serial SCSI / SAS Hard Drive - Refurbished

The HGST Ultrastar™ 7K3000 is the world’s first and only 7200 RPM hard drive rated at 2.0 million hours MTBF and backed by a five-year limited warranty. The Ultrastar 7K3000 represents the fifth-generation HGST 5-platter mechanical design, first introduced in 2004, and has been field proven by top server and storage OEMs as well as leading Internet giants. When the highest quality and reliability are a top requirement, customer field data proves that the Ultrastar 7K3000 delivers by reducing downtime, eliminating service calls and keeping TCO to a minimum. Engineered for the highest reliability, the Ultrastar 7K3000 is not only put through grueling design tests during development but must also pass stringent ongoing reliability testing during manufacturing. Across the entire Ultrastar family, world-class quality control, combined with scientific root-cause analysis and multi-faceted corrective actions, ensure that HGST remains the recognized leader in quality and reliability for enterprise-class hard drives.



Highlights

• 2.0 million hours MTBF

• Up to 3 terabytes of capacity

• 6Gb/s SATA and 6Gb/s SAS models for configuration flexibility

• Dual Stage Actuator (DSA) and Enhanced Rotational Vibration Safeguard (RVS) for robust performance in multi-drive environments

• 24x7 accessibility for enterprise-class, capacity-optimized applications

• 5-year limited warranty



Applications / Environments

• Cloud storage

• Massive Scale Out (MSO)

• Decision support & RAID

• Data warehousing & mining

• Disk-to-disk backup & archiving

• RAID arrays

• Network Attached Storage (NAS)

Hitachi Model: HUS723020ALS640


Compatibility:

This drive is compatible with any of our SAS drive trays and any of our SAS controllers.

A Full compatibility list can be found here:

http://www.hgst.com/tech/techlib.nsf/techdocs/D69C43185C42FA0B882579990007B55D/$file/US7K3000_CompatGuide_SAS_v1.0.pdf

Drive specification

0B26312

Formatted Gbytes (512 bytes/sector)

2000

Bytes per sector

512

Spindle speed (RPM)

7,200

I/O data transfer rate (MBps)

600

Cache buffer

64

Interface Type

6.0Gbps SAS

Seek time (read typical) ms

7.6

Dimensions (HxLxW) mm

26.1 / 146.99 / 101.6

Weight

0.69 kg

Temperature - Operating

5C -60C

Temperature - Non-operating

-40C - 70C


Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: HUS723020ALS640

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
