HGST Ultrastar He8 0F23267 / HUH728080ALE600 8TB SATA Hard Drive

(0) No Reviews Yet

Hitachi Part #/MPN: 0F23267

DiscTech Item #: HIT-0F23267-NP-OE


$269.00
$269.00

Enterprise Grade

Capacity: 8TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 205

Average Seek Time: 8.5/9.0

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 128MB

HGST Hitachi Ultrastar He8 0F23267 / HUH728080ALE600 8TB 3.5inch 6Gbps 7.2K RPM 512e Enterprise SATA Hard Disk Drive - New Pull

HGST Hitachi Ultrastar He8 0F23267 / HUH728080ALE600 8TB / 8000GB 6.0 Gb/s 7200 RPM 512e Enterprise Serial ATA HDD - New Pull

Ultrastar He8

HelioSeal® Delivers Twice the Capacity Using One-Quarter Less Power

One-third more capacity and 23% lower energy consumption. Available today. That’s the power of helium. Delivering the industry’s leading capacity at 8TB, Ultrastar He8 is based on the widely accepted and proven HelioSeal® platform. HelioSeal technology replaces air with helium inside the drive, reducing air turbulence and enabling 7Stac™, a seven-disk design in a traditional 3.5-inch form factor. Ultrastar He8 goes beyond what any air-based HDD can do and seamlessly integrates into virtually any mainstream enterprise environment. Cooler and quieter with industry-leading power efficiency (Watts/TB) and no-compromise performance, the Ultrastar He8 lays the foundation for future growth in massive scale-out environments.

TCOptimized™ – Increasing Storage Efficiency to Drive Down Data Center TCO

We recognize the growing pressures that data centers face. Volume is expanding, operating costs are rising while budgets remain flat. Lowering the total cost of ownership (TCO) has become the focus of data center architects. Ultrastar He8 provides the best TCO value proposition and delivers greater storage efficiency with breakthroughs in capacity, power efficiency and best-in-class performance. This HelioSeal hard drive achieves up to 3X higher random write performance than the prior generation, Ultrastar He6, thanks to HGST media cache architecture, a disk-based caching technology. He8 offers a 12Gb/s SAS (6Gb/s SATA) interface for easy integration into high performance data centers. Features like Rebuild Assist dramatically reduce RAID rebuild times and maintain system performance during the rebuild process. Learn more in our Rebuild Assist technical brief

Data Security with Industry-Leading Quality and Reliability

Compliance and privacy requirements drive the need for increased data security. Ultrastar He8 offers security and encryption options to protect data from unauthorized use. Instant Secure Erase (ISE) models expedite drive redeployment and retirement. Encryption models protect data with hardware-based encryption, including a Trusted Computing Group (TCG) option with FIPS 140-2 certification, Level 2. The Ultrastar He8 extends HGST’s long-standing tradition of reliability leadership with a 2.5M-hour MTBF rating and a 5-year limited warranty. HGSTs drive reliability and security options also help lower data center TCO.

HGST Quality and Service

HGST’s Ultrastar He8 extends the company’s long-standing tradition of performance and capacity leadership. The proven drive design enables high reliability and availability to customer data. Ultrastar quality, performance and world class technical support and service provides customers with a lower total cost of ownership over previous generations. HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of HDD, SSD and software solutions to help the world harness the power of data.

Highlights

  • Industry’s leading 8TB capacity in a standard 3.5-inch form factor

  • Industry’s best Idle and Active power efficiency (Watts/TB)Reliable, field-proven, 2nd generation HelioSeal® process and 7Stac™ design
  • Compared to 6TB air drives
    • 33% more capacity
    • 23% lower idle power
    • 44% more power efficient (Watts/TB)

  • SATA 6Gb/s and SAS 12Gb/s
    • 12Gb/s SAS compatible with next gen data centers; backwards compatible with 6Gb/s SAS)

  • 2.5M hours MTBF rating

  • Instant Secure Erase (SE) & Self-Encrypting Drive (SED options

  • Advanced format 4Kn and 512e models

Applications Environments

  • Enterprise and data center applications where capacity density and power efficiency are paramount
  • Cloud & Hyperscale storage
  • Massive scale-out High-density data centers (MSO)
  • Distributed Files Systems like Ceph™ and Hadoop® to support Big Data Analytics
  • RAID array
  • Video surveillance & content distribution
  • Ideal for all mainstream enterprise capacity applications


Compatibility:

This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives

Ultrastar He8
Model/Part No.0F23267
Alt Model/Part No.HUH728080ALE600
Configuration
Capacity8TB/8000GB
InterfaceSATA 6Gb/s
Format : Sector size (bytes)512e: 512
Max. Areal density (Gbits/sq. in)664
Performance
Data buffer (MB)128
Rotational speed (RPM)7200
Latency average (ms)4.16
Interface transfer rate (MB/s, max)600
Sustained transfer rate (MB/s, typ.)

(MiB/s, typical)



195

205
Seek time (read, ms, typical)8.5/90
Reliability
Error rate (non-recoverable, bits read)1 in 10E15
Load/Unload cycles (at 40°C)600,000
Availability (hrs/day x days/wk)24x7
MTBF (M hours)2.5
Annualized Failure Rate (AFR)0.35%
Acoustics
Idle (Bels, typical)2.0/3.6
Power
Requirement+5 VDC

+12 VDC
Operating7.4
Idle (W)5.1
Power consumption efficiency at idle (W/TB)

(Watts/TB)



0.64

0.00064
Physical size
z-height (mm)26.1
Dimensions (width x depth, mm)101.6 (+/- 0.25) x 147
Weight (g, max)650
Environmental (Operating)
Ambient temperature5°C to 60°C
Shock (half-sine wave, 2 ms, G)70
Vibration (G RMS 5 to 500 Hz)0.67 (XYZ)
Environmental (Non-Operating)
Ambient temperature-40°C to 70°C
Shock (half-sine wave, G)300 (1ms)/ 150 (11ms)
Random Vibration (G RMS 2 to 200 Hz)1.04 (XYZ)

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: HUH728080ALE600

Weight: 1.8 lb

Warranty: 1 Year DiscTech

New Pull

Condition Levels Explained

The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
