Hitachi Ultrastar 7K3000 0F12456 Enterprise SATA Hard Drive

(0) No Reviews Yet

Hitachi Part #/MPN: 0F12456

DiscTech Item #: HIT-0F12456-BN-5Y


$199.00
$199.00

Enterprise Grade

Capacity: 3TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 152

Average Seek Time: 8.2

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 64MB

Hitachi Ultrastar 7K3000 0F12456 / HUA723030ALA640  3000GB / 3TB 7.2K Enterprise SATA Hard Drive - Brand New

Highest capacity and reliability with a proven design

The Hitachi Ultrastar 7K3000 is the world’s first and only 7200 RPM hard drive rated at 2.0 million hours MTBF and backed by a five-year limited warranty. The Ultrastar 7K3000 represents the fifth-generation Hitachi 5-platter mechanical design, first introduced in 2004, and has been field proven by top server and storage OEMs as well as leading Internet giants. When the highest quality and reliability are a top requirement, customer field data proves that the Ultrastar 7K3000 delivers by reducing downtime, eliminating service calls and keeping TCO to a minimum.

Engineered for the highest reliability, the Ultrastar 7K3000 is not only put through grueling design tests during development but must also pass stringent ongoing reliability testing during manufacturing. Across the entire Ultrastar family, world-class quality control, combined with scientific root-cause analysis and multi-faceted corrective actions, ensure that Hitachi GST remains the recognized leader in quality and reliability for enterprise-class hard drives.

Highlights

• 2.0 million hours MTBF

• Up to 3 terabytes of capacity

• 6Gb/s SATA and 6Gb/s SAS models for configuration flexibility

• Dual Stage Actuator (DSA) and Enhanced Rotational Vibration Safeguard (RVS) for robust performance in multi-drive environments

• 24x7 accessibility for enterprise-class, capacity-optimized applications

• 5-year limited warranty



Applications / Environments

• Cloud storage

• Massive Scale Out (MSO)

• Decision support & RAID

• Data warehousing & mining

• Disk-to-disk backup & archiving

• RAID arrays

• Network Attached Storage (NAS)

Hitachi p/n: 0F12456 / HUA723030ALA640


Compatibility:

This drive is compatible with any system that uses SATA hard drives (up to 2.19TB).  Controllers with Long LBA capabilities will be able to utilize drives larger than 2.19TB.

Drive specification

0F12456 / HUA723030ALA640

Formatted Gbytes (512 bytes/sector)

3000

Bytes per sector

512

Spindle speed (RPM)

7,200

I/O data transfer rate (Mbytes/sec max)

600

Cache buffer

64 Mbytes

Height (max)

26.1 mm

Width (max)

101.6 mm

Length (max)

147 mm

Weight (max) grams

690

Average seek, read (msec typical)

8.2

Startup current (typical) 12V (peak)

2.4 amps

Idle mode (typical) watts

5.6

Ambient temperature

5° to 60°C (op.)

–40° to 70°C (nonop.)


Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: HUA723030ALA640

Weight: 1.8 lb

Warranty: 5 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

5 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
