IBM 9SX 5395-RU4 9SX5Kirt UPS 5000/VA / 4500W Uninterruptible Power Supply

IBM Part #/MPN: 5395-RU4

DiscTech Item #: IBM-5395-RU4-BN-OE

$2,995.00

Brand New
Condition Levels Explained
The product is brand new.
Warranty:1 Year DiscTech
Product Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
Low Stock:Call for ETA
Stock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back

$2,995.00

Interface Types: IEC C13, IEC C19

U Height: 3U

Wattage/VA: 4500W

Voltage: 110-240V Multi

IBM 9SX 5395-RU4 9SX5Kirt UPS 5000/VA / 4500W Uninterruptible Power Supply - Brand New

IBM 9SX 5395-RU4 UPS 5000/VA / 4500W Uninterruptible Power Supply - Brand New

Eaton 9SX UPS
The Eaton 9SX UPS offers high availability, flexibility and advanced protection for infrastructure, industrial, medical, IT, networking, storage and telecom. Delivering on-line double conversion protection in versatile Rack/Tower format with up to 95% efficiency.

Features

Online double conversion topology
Up to 94% efficiency in Online mode
Next-generation graphical LCD display (7 languages)
Provides more real power (watts) to protect more equipment with a 0.9 power factor
Energy metering - kWh values can be monitored using the LCD
Eaton ABM battery management technology uses an innovative three-stage charging technique that extends battery life by up to 50%

Alt Model #: 9SX5Kirt

Eaton 9SX 5000i RT3U UPS
Model/Part No.	5395-RU4
Alt Model/Part No.	9SX5KiRT
GENERAL
Topology	On-line double conversion with PFC (Power Factor Correction) system
Configuration	Rack/Tower
Rating (VA/Watts)	5000/4500
Dimensions (H x W x D, mm)	130 (3U) x 440 x 685
Weight (kg)	48
Rail Kit Included	Yes
ELECTRICAL INPUT
Connection	Hardwired
Input Voltage Range	176-276V without derating (up to 100–276V with derating)
Nominal Voltage	200/208/220/230/240V
Frequency	50/60 Hz autoselection
Frequency Range	40-70 Hz
Short Circuit Current	90 A
THDI	<5%
ELECTRICAL OUTPUT
Voltages	200/208/220/230/240V +/– 1%
Voltage THD	<2%
Output Receptacles	(8) IEC-320-C13 (2) IEC-320-C19 Hardwired
Overload Capacity	102–110% : 120s 110–125%: 60s 125–150%: 10s >150%: 500ms
Efficiency (Normal Mode)	Up to 94% in Online mode, 98% in Hi-Efficiency mode
Output Frequency	50/60 Hz autoselect, frequency converter as standard
Load Crest Factor	3:1
BATTERY
Battery Management	ABM® and Temperature compensated charging method (user selectable), automatic battery test, deep discharge protection, automatic recognition of external battery units.
Extended Battery Capability	EBM with Rack Kit
COMMUNICATIONS
User Interface	Multilingual graphical LCD display
Communication Ports	1 USB port 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously) 4 dry contacts (DB9) 1 mini terminal block for remote On/Off and 1 for remote power Off
Communication Slot	1 slot for Network-MS card ModBus-MS or Relay-MS cards
ENVIRONMENTAL & STANDARDS
Audible Noise	<45dB
Operating Temperature	0 to 40°C continuous
Safety Markings	IEC/EN 62040-1 UL 1778 CSA 22.2
EMC Markings	IEC/EN 62040 -2 FCC Class A IEC/EN 62040-3 (Performance) C-Tick
Approvals	CE CB report (TUV) UL

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 9SX5KIRT

Weight: 110 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty

IBM 5395-RU4 5000/VA / 4500W Uninterruptible Power Supply
