IBM 81Y9596 600GB 10K Serial SCSI / SAS Hard Drive

IBM Part #/MPN: 81Y9596

DiscTech Item #: IBM-81Y9596-RF-OE


$249.00
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$249.00

Enterprise Grade

Capacity: 600GB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Average Seek Time: 4.0

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

IBM 81Y9596 600GB 10K 6.0Gbps SFF Serial SCSI / SAS Hard Drive - Refurbished

This 2.5-inch enterprise disc drive makes possible a new class of high I/O, high-density storage solutions. Space-constrained data centers are enabled to achieve higher IOPs (input/output per second) performance in small form factor system configurations while maintaining the highest levels of reliability.

These drives combine giant magnetoresistive (GMR) heads, partial response/maximum likelihood (PRML) read channel electronics, embedded servo technology, and a Serial Attached SCSI (SAS) interface to provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements.

IBM FRU: 81Y9600

IBM PN: 81Y9599

IBM Option: 81Y9596


Compatibility:

This drive is compatible with select IBM SFF (Small Form Factor) Servers & Storage Systems.  Long Caddy

System Storage by IBM only.

**NOT compatible with System X**

Specifications600 GB
Model Number81Y9596
Capacity
Interface6-Gb/s SAS
Performance
Spindle Speed (RPM)10K
Read Seek Time Typical4.0 ms
Average Latency3.0 ms
Physical
Width (in/mm)2.76/70.1
Depth (in/mm)3.945/100.2
Weight (lb/kg)0.5/0.21

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 9PN066-039 81Y9600 81Y9599

Weight: 1 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
