Maxtor Part #/MPN: XT1085
DiscTech Item #: MAX-XT1085-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Call for Lead TimeSpecial Order - Call for Lead Time
This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Capacity: 1GB
Speed: 3,600RPM
Interface Types: SCSI 50pin
Form Factor: 5.25inx3.2in Full Height Drive
Sector Size: 512 / 512e
Average Seek Time: 12.5
Electrical Interface: SCSI II Fast - 10MBps 16-bit
MAXTOR XT1085 80MB 3600 RPM Full Height 506 MFM 5.25 inch hard drive - Refurbished
MAXTOR XT1085 80MB 3600 RPM Full Height 506 MFM 5.25 inch hard drive
The XT-1000/2000 disk drives are high capacity, high performance random access storage devices utilizing from 5 to 8 non removable 5 1/4 inch disks as storage mdia. each disk surface employs one movable heard to access up to 1224 data tracks. The total unformatted capacity of the disk drives random from 85.32 to 239.98 MB
Model: | XT1085 |
---|---|
Interface Type | 506 MFM |
Formatted Capacity (MB) | 80MB |
Sectors Per Track | |
Actuator Type | |
Cylinders_Physical | |
Heads_Physical | |
Discs (3.5in) | |
Media Type | |
Recording Method | Rotary voice coil and closed loop servo system for fast, accurate head positioning |
Internal Transfer Rate (Mbps) | 5.0 megabit/second |
External Transfer Rate (MBps) | 7.5 megabit/second transfer rate for drives utilizing RLL 2.7 encoding |
Spindle Speed (RPM) | |
Average Latency (ms) | 8.33ms |
Buffer (KB) | |
Interface Speed | ST412/506 |
Sectors Per Drive | |
TPI (Tracks Per Inch) | |
BPI (Bits Per Inch) | |
Average Seek (ms) | |
Single Track Seek (ms) | |
Max Full Seek (ms) | |
MTBF | 30,000 POH, typical usage |
Shock (G's) Operating | |
Accoustics (dBa) Idle |
Weight: 5 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
