Seagate Constellation ES 1TB 7.2K ST1000NM0001 Serial Attached SCSI / SAS Hard Disk Drive

(0) No Reviews Yet

Seagate Part #/MPN: ST1000NM0001

DiscTech Item #: SGT-ST1000NM0001-FR-1Y


Enterprise Grade

Capacity: 1TB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 147

Average Seek Time: 8.5 / 9.5

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Drive specification


Formatted Gbytes (512 bytes/sector)


Bytes per sector


Spindle speed (RPM)


I/O data transfer rate (MBps)


Cache buffer


Interface Type

6.0Gbps SAS

Seek time (read / write) ms

8.5 / 9.5

Average Latency


Dimensions (HxLxW) mm

26.1 / 147 / 101.85


0.640 kg

Operating Shock (Read)

70G, 2ms

Non-operating Shock

300G, 2ms

Temperature - Operating

5C -60C

Temperature - Non-operating

-40C - 70C


1,200,000 hrs

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 9YZ264 9YZ264-002

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Factory Refurbished

Condition Levels Explained

The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
