Seagate Part #/MPN: ST3500414SS
DiscTech Item #: SGT-ST3500414SS-FR-6M
- Factory RefurbishedCondition Levels Explained
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
Product Warranties ExplainedThe product has a manufacturer warranty for the time period specified.
- Warranty:6 Month Manufacturer
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 500GB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 150
Average Seek Time: 8.5 / 9.5
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 16MB
Seagate Constellation ES ST3500414SS 500GB 7.2K 6.0Gbps Serial SCSI / SAS Hard Drive - Factory Refurbished
• Fourth-generation, enterprise, nearline drive designed for 24×7 operation
• Up to 2-TB capacity for data-hungry enterprise business applications
• Best-in-class enhanced rotational vibration tolerance ensures unrivalled
performance in high-density applications requiring continuous data access
• Enhanced efficiencies with PowerChoice™ host-selectable power options,
for unprecedented savings (up to 92 per cent) during slow or idling periods
• Proven reliability with multi-drive firmware maximised for enterprise
system availability
• Robust performance with dual processor technology and ramp load
technology (35 per cent average sustained throughput increase over
previous generation)
• Provides business sustainability with Seagate® Unified Storage architecture
- 6-Gb/s SAS performance with error detection and correction (IOEDC/
IOECC) capabilities for the ultimate in data integrity
- US Government-grade Self-Encrypting Drive (SED) option for TCGcompliant/
AES-128 security cuts IT drive retirement costs, while
protecting data securely¹
Compatibility:
This drive is compatible with any of our SAS drive trays and any of our SAS controllers.
Drive specification | ST3500414SS |
Formatted Gbytes (512 bytes/sector) | 500 |
Bytes per sector | 512 |
Spindle speed (RPM) | 7,200 |
I/O data transfer rate (MBps) | 600 |
Cache buffer | 16 |
Interface Type | 6.0Gbps SAS |
Seek time (read / write) ms | 8.5 / 9.5 |
Track-to-track seek (read / write) ms | 0.8 / 1.0 |
Dimensions (HxLxW) mm | 26.1 / 146.99 / 101.6 |
Weight | 0.61 kg |
Operating Shock (Read) | 70G, 2ms |
Non-operating Shock | 400G, 2ms |
Temperature - Operating | 5C -55C |
Temperature - Non-operating | -40C - 70C |
Current Requirements 12VDC (Read/Write, Idle) | 3.5w / 2.6w |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 6 Month Manufacturer
Factory Refurbished
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
The product has a manufacturer warranty for the time period specified.
6 Month Manufacturer Warranty
