Seagate Constellation ST9160511NS SATA Enterprise Hard Drive

Seagate Part #/MPN: ST9160511NS

DiscTech Item #: SGT-ST9160511NS-BN-OE-DEL

$175.00
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:1 Year DiscTech
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back
$175.00

Enterprise Grade

Capacity: 160GB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 95

Average Seek Time: 8.5 / 9.5

Electrical Interface: SATA 300 - 3.0Gbps

On-Board Cache: 32MB

Seagate Constellation ST9160511NS 160GB 7.2K 2.5" SFF SATA  Enterprise Hard Drive - Brand New

The Constellation 7200 hard drive enables manageable nearline storage solutions in 2.5" chassis — either direct attach or in a tiered storage environment — at the lowest power usage without compromising performance or reliability. Constellation 500GB SATA drives deliver cost-effective, eco-friendly nearline storage.

Key Features and Benefits
  • Lowest operating power & enhanced power options with PowerChoice™ for even greater power savings during slow or idle periods
  • First 2.5", 15mm business critical drive on the market designed for enterprise reliability, vibration performance and high data integrity. Fits in more server & storage slots!
  • Fastest Tier 2/Nearline HDD on the market (SAS @ 6Gb/s speed). At a system level (with more drives) the performance will be >2x as compared to 3.5" HDD.
  • The highest capacity 2.5" enterprise drive with 500GB with both SAS and SATA interfaces. (160GB SATA also available for boot/entry server applications)
  • 6Gbps SAS 2.0 allows for easier integration, enhanced features and outstanding performance
  • Government-grade self-encrypting drive (SED) on SAS models
  • Best performing nearline drive with Best-in-class Rotational Vibration

 DP/N:

K836N 0K836N

Compatibility:

This drive is compatible with any of our SATA drive trays and any of our SATA controllers.

Drive specification

ST9160511NS

Formatted Gbytes (512 bytes/sector)

160

Bytes per sector

512

Spindle speed (RPM)

7,200

I/O data transfer rate (MBps)

300

Cache buffer

32

Interface Type

Serial ATA-300

Average latency

4.16 ms

Seek time (read / write) ms

8.5 / 9.5

Track-to-track seek (read / write) ms

0.8 / 1.0

Dimensions (HxLxW) mm

14.8 / 100.5 / 70

Weight

0.188 kg

Operating Shock (Read)

70G, 2ms

Non-operating Shock

400G, 2ms

Temperature - Operating

5C -55C

Temperature - Non-operating

-40C - 70C

Current Requirements 12VDC (Read/Write, Idle)

2.8w / 2.3w

Click here to view the manufacturer's item description/brochure

Alternate MPNs: K836N 0K836N

Weight: 1.8 lb

Warranty: 1 Year DiscTech
