Seagate Part #/MPN: ST4000VX000
DiscTech Item #: SGT-ST4000VX000-BN-3Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:3 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 4TB
Speed: 5,900RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 180MB/s
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 64MB
Seagate Surveillance ST4000VX000 / 1F4168-500 4TB 6Gbps 5.9K RPM 512e SATA HDD - Brand New
Seagate Surveillance ST4000VX000 4TB / 4000GB 6Gbps 5900 RPM 4K Native Serial ATA Hard Disk Dive - Brand New
Seagate Product Number: 1F168-500
Surveillance HDD
The New Generation SV Drive
- The industry's first surveillance-optimized hard drive precision-tuned for high write surveillance workloads operating 24x7
- Capacities up to 8TB support 64 cameras per drive and 8+ drives per system
- Engineered for workloads of 180TB/year, three times that of desktop drives
- Low power consumption and startup current to minimize heat and vibration emission, improving long-term drive reliability
- Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability
- Customize power settings for incremental savings during system downtime without compromising time to record
- Reliable performance in multi-drive systems with support from RV sensors
- Optional 3-year +Rescue Data Recovery Service plan to help protect against data loss from viruses, software issues or mechanical and electrical breakdowns
Best-Fit Application
- NVR
- Embedded SDVR
- Hybrid SDVR
- Surveillance DVR
Compatibility:
This drive is compatible with any server that accepts 4TB 3.5in x 1.0in (LFF) SATA drives.
| Surveillance HDD | |
|---|---|
| Performance | |
| +Rescue Data Recovery Service | |
| Voltage | |
| Power Management | |
| Environmental/Temperature | |
| Reliability | |
| Physical | |
| Standard Model Numbers | ST4000VX000 |
| Seagate Product Number | 1F4168-500 |
| Capacity | 4TB / 4000GB |
| Interface | SATA 6Gb/s |
| Cache | 64MB |
| Bytes per Sector | Advance Format 4096 - (4K physical emulated at 512-byte sectors) |
| R/V (Rotational Vibration) Sensor | Yes |
| Drive bays supported | 8+ |
| Cameras Supported | Up to 64 |
| Max Sustainable Transfer Rate | 180MB/s |
| 3 Year Option with +Rescue Model | Yes |
| Voltage Tolerance, Inc. Noise (5V) | ±5% |
| Voltage Tolerance, Inc. Noise (12V) | ±10% |
| Startup Power (12V, A) | 1.8 |
| Average Operating Power | 5.6W |
| Idle Average (W) | 4W |
| Standby Mode | 0.5W |
| Sleep Mode | 0.5W |
| Operating (ambient, min) | 0°C |
| Operating (drive case, max) | 70°C |
| Nonoperating (ambient, min) | -40°C |
| Nonoperating (ambient, max) | 70°C |
| Tarnish Resistant | Yes |
| Load/Unload Cycles | 300,000 |
| Nonrecoverable Read Errors per Bits Read, Max | 1 per 10E14 |
| MTBF (Hours) | 1,000,000hr |
| Power-On Hours | 8760 |
| Height (mm/in) | 26.11mm/1.028n |
| Width (mm/in, max) | 101.6mm/4in |
| Depth (mm/in, max) | 146.99mm/5.787in |
| Weight (g/lb) | 610g/1.345lb |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1F4168-500
Weight: 1.8 lb
Warranty: 3 Year Manufacturer
Brand New
The product is brand new.
3 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
