Seagate ST6000NM0034 6000GB SAS Hard Drive

Seagate Part #/MPN: ST6000NM0034

DiscTech Item #: SGT-ST6000NM0034-FR-OE


$170.00
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$170.00

Enterprise Grade

Capacity: 6TB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: up to 226

Average Seek Time: 4.16

Electrical Interface: SATA 150 - 1.50Gbps

On-Board Cache: 128MB

Seagate ST6000NM0034 6TB / 6000GB 3.5in 12.0Gbps 7200 RPM Enterprise SAS Hard Drive - Factory Recertified

Alt. MPN: 1HT27Z, 1HT27Z-001

Capacity-Optimized Enterprise Hard Drive for Bulk-Data Applications

  • Highest-capacity large form factor enterprise drive—50% more capacity over last generation with up to 6TB—for demanding data growth
  • Fastest high-capacity HDD with best-in-class random and sequential read/write Performance
  • Eighth-generation drive technology for reliable access to bulk storage of unstructured data
  • 12Gb/s SAS interface for easy integration into replicated and RAID storage systems
  • Enhanced error correction, super parity and end-to-end SAS-based data integrity for accurate data storage
  • Industry-leading rotational vibration tolerance ensures consistent performance.
  • Improved power and cooling efficiencies with low power consumption and on-demand PowerChoice™ technology based on T10/T13 power management standards
  • Engineered for 24×7 workloads of 550TB/yr—10× that of desktop drives
  • Robust performance with dual processors, ramp load technology, top-cover-attached motor and humidity sensor for optimum performance in all chassis.

Best-Fit Applications

  • Hyperscale applications
  • High-capacity RAID storage
  • Mainstream enterprise external storage arrays (SAN, NAS, DAS)
  • Cloud data centers—replicated bulk data storage
  • Enterprise backup and restore—D2D, virtual tape
  • Centralized surveillance


Compatibility:

This drive is compatible with any server that accepts 3.5" x 1.0" (LFF Hard Drive) SAS drives.

Drive ModelST6000NM0034
Capacity6TB/6000GB
InterfaceSAS 12Gbps
Self-Encrypted DriveNo
Features
Protection Information (T10 DIF)Yes
Humidity SensorYes
Super ParityYes
Low HalogenYes
PowerChoice TechnologyYes
Cache, Multisegmented (MB) Yes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours) 1.4M
Reliability Rating @ Full 24x7 Operation (AFR) 0.63%
Nonrecoverable Read Errors per Bits Read1 sector per 10E15
Power-On Hours per Year8760 (24x7)
Sector Size (Bytes per Logical Sector) 512/4096
Performance
Spindle Speed (RPM) 7200
Interface Access Speed (Gb/s) 12.0
Max. Sustained Transfer Rate OD (MB/s) up to 226
Average Latency (ms) 4.16
Interface PortsDual
Rotation Vibration @ 1500 Hz (rad/s) 12.5
Power Consumption
Idle Power, Average (W) 7.97
Typical Operating, Random Read (W) 11.86
Power Supply Requirements+12V and +5V
Enviromental
Temperature, Operating (°C) 5 to 60
Vibration, Nonoperating: 10Hz to 500Hz (Grms) 4.9
Shock, Operating, 2ms (Read/Write) (Gs) 70/40
Shock, Nonoperating, 1ms and 2ms (Gs) 250
Physical
Height (mm/in) 26.1/1.028
Width (mm/in) 101.85/4.010
Depth (mm/in) 147/5.878
Weight (g/lb) 780/1.720

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 1HT27Z 1HT27Z-001

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Factory Refurbished

Condition Levels Explained

The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
