Seagate Part #/MPN: ST9300503SS
DiscTech Item #: SGT-ST9300503SS-BN-OE-DEL
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 300GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 67 to 129
Average Seek Time: 4.2/4.6
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 16MB
Compatible Systems: Dell 10th Gen. 2950 / 6950
Seagate Savvio ST9300503SS 10K.3 300GB 10K 6Gbps SFF SED (Self Encrypting) Serial SCSI / SAS Hard Drive - Brand New OEM
DPN: R744K V3D7F
Seagate® Savvio® 10K 2.5-inch self encrypting drives deliver unmatched reliability with the highest capacity, low cost-per-gigabyte and the lowest power profile of any mission-critical Tier 1, enterprise drive.
Key Features and Benefits
- World's highest-capacity 2.5-inch 10K-RPM drive (up to 600GB)
- Delivers 20 percent higher reliability than any other drive available as the industry’s first 2M-hour MTBF* drive to provide a 0.44 percent annualized failure rate (AFR)
- Includes second-generation 6Gb/s SAS with dual-port communication and is the first SFF hard drive with 4Gb/s FC support
- Reduces end-user cooling and energy costs with SFF and low power consumption
- Features PowerChoice™ technology for T10-compliant power management, empowering IT organizations to tailor systems for performance and power consumption
- Detects corruption of data in flight between the host system and the drive with the Protection Information (PI) option
- Improves device handling reliability with the head ramp load/unload feature
- TCG-compliant, Self-Encrypting Drive (SED) security option (SAS models only) eliminates the need to overwrite or physically destroy drives, enables safe return of drives for warranty or expired lease purposes and allows organizations to securely repurpose or sell hard drives**
*Mean time between failures
**Not available in all countries
DPN: R744K
Compatibility:
All SAS compatible servers including (This list is not all inclusive):
Dell PowerEdge 1900, 1950, 1955, 2900, 2950, 6900, 6950 Servers and MD1120 Storage Arrays.
Compaq/HP Proliant:
BL20p G4, BL460c, BL465c, BL480c, DL360 G4p, DL360 G5, DL380 G4, DL380 G5, DL385, DL385 G2, DL580 G3, DL580 G4, DL585, DL585 G2, ML350 G5, ML370 G4, ML370 G5, ML570 G3, ML570 G4
Seagate® Savvio® 10K.3 6-Gb/s SAS 2.0 300-GB Hard Drive with Secure Encryption
ST9300503SS
| Specifications | |
|---|---|
| Model Number | ST9300503SS |
| Interface | 6-Gb/s SAS |
| Cache | 16MB |
| Capacity | 300GB |
| Areal density (avg) | 252Gb/in2 |
| Guaranteed Sectors | 585,937,500 |
| PHYSICAL | |
| Height | 14.8mm (0.583 in) |
| Width | 70mm (2.76 in) |
| Length | 100.5mm (3.957 in) |
| Weight (typical) | 227g (0.50 lb) |
| PERFORMANCE | |
| Spin Speed | 10,000 RPM |
| Average latency | 3.0ms |
| Random read seek time | 4.2ms |
| Random write seek time | 4.6ms |
| RELIABILITY | |
| MTBF | 1,600,000 hours |
| Annual Failure Rate | 0.55 |
| POWER | |
| 12V start max current | 2.05A |
| 5V start max current | 0.72A |
| Features | |
| Storage Type | HDD |
| Encryption | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: R744K V3D7F 0R744K 0V3D7F
