Ubiquiti Networks Part #/MPN: NBE-M5-16
DiscTech Item #: UBI-NBE-M5-16-BN-1Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: Ethernet RJ45
Electrical Interface: Ethernet Gigabit - 1Gbps
Bays/Ports/Slots: 1
Wattage/VA: 6W
Voltage: 24V
Ubiquiti Networks NBE-M5-16 NanoBeam M5 Bridge - Brand New
Ubiquiti Networks NBE-M5-16 NanoBeam M5 5GHz High-Performance Bridge - Brand New
Overview
Starting with the first-generation NanoBridge®, Ubiquiti Networks® pioneered the all-in-one design for an airMAX® product functioning as a CPE (Customer Premises Equipment). Now Ubiquiti Networks launches the latest generation of CPE, the NanoBeam®.
Improved Noise Immunity
The NanoBeam directs RF energy in a tighter beamwidth. With the focus in one direction, the NanoBeam blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency
Integrated Design
The Ubiquiti Research and Development team combined the radio and antenna to create a more efficient and compact CPE. The NanoBeam gets maximum gain out of the smallest footprint.
Providing increased performance from its faster processor and innovative mechanical design at a low cost, the NanoBeam is extremely versatile and cost-effective to deploy.
airMAX Technology Included
Unlike standard Wi-Fi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots scheduled by an intelligent AP controller.
This time slot method eliminates hidden node collisions and maximizes airtime efficiency. It provides significant performance improvements in latency, throughput, and scalability compared to all other outdoor systems in its class.
- Intelligent QoS Priority is given to voice/video for seamless streaming.
- Scalability High capacity and scalability.
- Long Distance Capable of high-speed, carrier-class links.
SYSTEM AND REGULATORY/COMPLIANCE | |
---|---|
Model Number | NBE-M5-16 |
Processor Specs | Atheros MIPS 74c 560 MHz |
Memory | 64 MB DDR2 8 MB Flash |
Networking Interface | (1) 10/100 Ethernet Port |
Wireless Approvals | FCC IC CE |
RoHS Compliance | Yes |
PHYSICAL/ELECTRICAL/ENVIRONMENTAL | |
Dimensions | 140 x 140 x 54 (5.51 x 5.51 x 2.13 in) |
Weight | 0.320 kg (0.71 lb) |
Power Supply | 24V 0.5A PoE |
Power Method | Passive Poe (Pairs 4, 5+; 7, 8 Return) |
Max Power Consumption | 6W |
Gain | 16 dBi |
Wind Loading | 21.4 N @ 200 km/h (4.8 Ibf @ 125 mph) |
Wind Survivability | 200 km/h 125 mph |
LEDs | (1) Power (1) LAN (4) WLAN |
Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
Channel Sizes | 5/8/10/20/30/40 MHz |
Polarization | Dual-Linear |
Enclosure | Outdoor UV Stabilized Plastic |
Mounting | Pole-Mount (Kit Incuded) Wall-Mount |
ESD/EMP Protection | Air: +/- 24 kV Contact +/- 24 kV |
Operating Temperature | -40 to 70° C (-40 to 158°F) |
Operating Humidity | 5 to 95% Noncondensing |
Salt Fog Test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G Method 509.5 |
Vibration Test | IEC 68-2-6 |
Temperature Shock Test | 68-2-14 |
UV Test | IEC 68-2-5 at 40°C (104°F) Equivalent: ETS 300 019-1-4 |
Wind-Driven Rain Test | ETS 300 019-1-4 Equivalent: MIL-STD-810 Method 506.5 |
OPERATING FREQUENCY | |
Worldwide | 5170 - 5875 MHz |
USA | 5725 - 5850 MHz |
ANTENNA INFORMATION | |
Gain | 16 dBi |
Max VSWR | 1.5:1 |
