Western Digital Part #/MPN: WD5000AADS
DiscTech Item #: WDC-WD5000AADS-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 500GB
Speed: 5,400RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 16MB
Western Digital Caviar Green WD5000AADS 500GB 3.5" Enterprise SATA IntelliPower Hard Drive - Refurbished
Reduced power consumption
WD has reduced power consumption making it possible for our energyconscious customers to build systems with higher capacities and the right balance of system performance, ensured reliability, and energy conservation.
Cool and quiet
Drives with WD GreenPower Technology™ yield lower operating temperatures for increased reliability and low acoustics for ultra-quiet PCs and external drives.
Perfect for external drives
External drive manufacturers can eliminate the need for a fan in a high-capacity product with a WD Caviar Green drive, the coolest and quietest in its class.
IntelliPower
A fine-tuned balance of spin speed, transfer rate, and caching algorithms designed to deliver both significant power savings and solid performance. Additionally, WD Caviar Green drives consume less current during startup allowing lower peak loads on systems as they are booted.
IntelliSeek™
Calculates optimum seek speeds to lower power consumption, noise, and vibration.
NoTouch™ramp load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Advanced Format (AF)
Technology being adopted by WD and other drive manufacturers as one of multiple ways to continue growing hard drive capacities. AF is a more efficient media format that enables increased areal densities. (RX, DX, and RS models only)
Compatibility:
This drive is compatible with any of our 3.5" SATA drive trays and any computer / server that uses SATA drives.
Specifications | |
---|---|
Model number | WD5000AADS |
Model Name | Caviar Green |
Formatted Capacity | 500 Gbytes |
Rotational Speed | IntelliPower |
Default Buffer (cache) Size | 64 Mbytes |
Performance | |
External (I/O) Transfer Rate (max) | 300 MBytes/sec |
Average Latency | 4.2 msec |
Physical | |
Form Factor(width) | 3.5-inch |
Form Factor(height) | 1-inch |
Height | 25.4 mm |
Width | 101.6 mm |
Length | 146.05 mm |
Weight | 0.69 kg |
Electrical | |
Power 12VDC (Rd/Wr; Idle; Standby; Sleep) | 490 mA; 470 mA; 5mA; 5mA |
Power 5VDC (Rd/Wr; Idle; Standby; Sleep) | 500 mA; 420 mA; 160mA; 160mA |
Environmental | |
Max Operating Shock (2-msec) | 65 Gs |
Max Nonoperating Shock (2-msec) | 250 Gs |
Operating Vibration (max) | .75 Gs |
Nonoperating Vibration (max) | 4.0 Gs |
Operating Temperature (max) | 60 deg C |
Operating Temperature (min) | 0 deg C |
Nonoperating Temperature (max) | 70 deg C |
Nonoperating Temperature (min) | -40 deg C |
Acoustical | |
Acoustics, Idle (sound power, typ) | 28 dBA |
MTBF (Hours) | 1,200,000 hours |
Nonrecoverable Read Errors | 1 per 10^16 bits read |
Supports S.M.A.R.T. | Yes |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
