Western Digital S25 WD3000BKFG SAS Enterprise Hard Drive

(0) No Reviews Yet

Western Digital Part #/MPN: WD3000BKFG

DiscTech Item #: WDC-WD3000BKFG-BN-OE


Enterprise Grade

Capacity: 300GB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 128

Average Seek Time: 3.6 / 4.2

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 16MB

Physical Specifications

Capacity300 GB147 GB
InterfaceSAS 6 Gb/s (WD3000BKFG)

SAS 3 Gb/s (WD3000BKFF)
SAS 6 Gb/s (WD1460BKFG)

SAS 3 Gb/s (WD1460BKFF)
Form Factor2.5-inch Drive2.5-inch Drive
User Sectors Per Drive586,072,368287,186,256
Warranty5 Years5 Years

Performance Specifications

Rotational Speed10,000 RPM (nominal)
Buffer Size16 MB
Average Latency3.00 ms (nominal)
Read Seek Time3.6 ms (average)
Write Seek Time4.2 ms (average)
Track-To-Track Seek Time0.7 ms (average)
Transfer Rate (Buffer To Disk)128 MB/s (Sustained)

Physical Dimensions

Height0.59 Inches (15 mm)
Length3.94 Inches (100 mm)
Width2.75 inches (69.85 mm)
Weight0.48 Pounds (219 gm)

Environmental Specifications

Operating Shock (Read)65G, 2 ms
Non-operating Shock300G, 2 ms
Idle Mode27 dBA (average)
Seek Mode 034 dBA (average)
Operating41° F to 131° F (5° C to 55° C)
Non-operating-40° F to 158° F (-40° C to 70° C)
Operating5-95% RH non-condensing
Non-operating5-95% RH non-condensing
Vibration (Operating)
Linear20-300 Hz, .75G (0 to peak)
Random0.004 g²/Hz (10 to 300 Hz)
Vibration (Non-operating)
Low Frequency0.05 g²/Hz (10 to 300 Hz)
High Frequency20-500 Hz, 4.0G (0 to peak)

Electrical Specifications

Current Requirements 12 VDC
Read/Write300 mA
Idle140 mA
Current Requirements 5 VDC
Read/Write750 mA
Idle700 mA
Power Dissipation
Read/Write7.35 Watts
Idle5.18 Watt

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new & sealed in retail box packaging.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
