Western Digital Part #/MPN: WD10EVVS
DiscTech Item #: WDC-WD10EVVS-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 1TB
Speed: 5,400RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 111
Average Seek Time: 4.2
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 8MB
Western Digital WD10EVVS 1TB 3.5" 3Gbps IntelliPower AV-GP SATA HDD - Refurbished
Western Digital WD10EVVS 1TB 3.5" 3Gbps IntelliPower AV-GP SATA HDD - Refurbished
Product Features
24x7 Reliability
These drives are designed to last in always-on, streaming digital audio/ video environments such as PVR/DVR, DVR recorders, and surveillance video recorders.
Reduced Power Consumption
With the combination of WD’s IntelliSeek, IntelliPark, and IntelliPower technologies, WD has reduced power consumption by up to 40 percent, compared to competitors’ drives. Lower power means less heat and better reliability
Quiet
Noise levels have been minimized to less than one sone – virtually below the threshold of human hearing
SilkStream™
Optimized for smooth, continuous digital video playback of up to twelve simultaneous HD streams. SilkStream in compatible with the ATA steaming command set so CE customers can use standard streaming management and error recovery options.
IntelliSeek™
Calculates optimum seek speeds to lower power consumption, noise, and vibration.
IntelliPower™
A fine-tuned balance of spin speed, transfer rate, and caching algorithms designed to deliver both significant power savings and solid performance.
IntelliPark™
Parks the recording heads off the disk surface during spin up, spin down, and when the drive is off. This ensures the recording head never touches the disk surface resulting in improved long term reliability due to less head wear, and improved non-operational shock tolerance.
Preemptive Wear Leveling (PWL)
The drive arm frequently sweeps across the disk to reduce uneven wear on the drive surface common to audio video streaming applications.
1 Million Hours MTBF
Best-in-class reliability for mainstream 3.5-inch form-factor AV storage
Compatibility:
This drive is compatible with any server that accepts 3.5"x1" (LFF) SATA drives.
| SPECIFICATIONS | |
|---|---|
| Model Number | WD10EVVS |
| Capacity | 1TB |
| Formatted Capacity | 1,000,204 MB |
| User Sector per Drive | 1,953,525,168 |
| Advanced Format (AF) | No |
| Native Command Queuing | Yes |
| SATA Latching Connector | Yes |
| Form Factor | 3.5-inch |
| PERFORMANCE | |
| Data Transfer Rate (max) Buffer to Host (SATA) Host to/from Drive (Sustained) | 3 Gb/s 111 MB/s |
| Cache (MB) | 8 |
| Average Latency (ms) | 4.2 |
| Rotational Speed (RPM) | IntelliPower |
| Average Drive Ready Time (sec) | 14.3 |
| RELIABILITY/DATA INTEGRITY | |
| Load/Unload Cycles | 300,000 |
| Non-Recoverable Read Errors | <1 in 10e14 |
| POWER MANAGEMENT | |
| 12VDC (A, max) | 1.671 |
| Average Power Requirements (W) Read/Write Idle Standby Sleep | 4.9 4.2 0.4 0.4 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature (°C) Base Casting (max) Operating Non-Operating | 70 0 to 60 -40 to 70 |
| Shock Operating (2 ms, read/write) Operating (2 ms, read) Non-operating (2 ms) | 30 65 300 |
| Average Acoustics (dBa) Idle Mode Quiet Seek Mode | 24 25 |
| PHYSICAL DIMENSIONS | |
| Height (in./mm, max) | 1.028/26.1 |
| Length (in./mm, max) | 5.787/147 |
| Width (in./mm, ± .01 in.) | 4/101.6 |
| Weight (lb./kg, ± 10%) | 1.32/0.60 |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
