Western Digital WD7502ABYS Caviar RE3 SATA Hard Drive

(0) No Reviews Yet

Western Digital Part #/MPN: WD7502ABYS

DiscTech Item #: WDC-WD7502ABYS-BN-OE-DEL


$165.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$165.00

Enterprise Grade

Capacity: 750GB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Average Seek Time: 8.9 / 9.6

Electrical Interface: SATA 300 - 3.0Gbps

On-Board Cache: 32MB

Specifications
Model number WD7502ABYS
Model Name RE3
Formatted Capacity 750 Gbytes
Rotational Speed 7,200 rpm
Default Buffer (cache) Size 32 Mbytes
Performance
External (I/O) Transfer Rate (max) 300 MBytes/sec
Average Seek Time, Read 8.9 msec typical
Average Seek Time, Write 9.6 msec typical
Average Latency 4.2 msec
Physical
Form Factor(width) 3.5-inch
Form Factor(height) 1-inch
Height 1.028 inch
Width 4.0 inch
Length 5.787 inch
Weight 1.52 pounds
Electrical
Power (Typical)8.4 watts
Power (Idle)7.8 watts
Environmental
Max Operating Shock (2-msec) 65 Gs
Max Nonoperating Shock (2-msec) 250 Gs
Operating Vibration (max) .75 Gs
Nonoperating Vibration (max) 4.0 Gs
Operating Temperature (max) 60 deg C
Operating Temperature (min) 0 deg C
Nonoperating Temperature (max) 70 deg C
Nonoperating Temperature (min) -40 deg C
Acoustical
Acoustics, Idle (sound power, typ) 33 dBA

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 0G631F G631F WD7502ABYS-18A6B0 MY-0G631F-12555-94O-0199-A00

Weight: 1.8

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new & sealed in retail box packaging.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
