Western Digital WD9001BKHG 900GB 10K SAS 2.5" Hard Disk Drive

(0) No Reviews Yet

Western Digital Part #/MPN: WD9001BKHG

DiscTech Item #: WDC-WD9001BKHG-BN-OE-DEL


$239.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$239.00

Enterprise Grade

Capacity: 900GB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 204

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 32MB

Specifications
Model number WD9001BKHG
Model Name S25
Formatted Capacity 900 Gbytes
Rotational Speed 10,000 rpm
Default Buffer (cache) Size 32 Mbytes
Sectors per drive1,758,174,768
ROHS CompliantYes
Performance
External (I/O) Transfer Rate (max) 204 MBytes/sec
Physical
Form Factor(width) 2.75-inch
Form Factor(height) .59-inch
Height 15 mm
Width 69.85 mm
Length 100 mm
Weight 0.23 kg
Electrical
Power Dissipation Read/Write .7.80 watts
Environmental
Max Operating Shock (2-msec) 65 Gs
Max Nonoperating Shock (2-msec) 300 Gs
Operating Vibration (max) .5 Gs
Nonoperating Vibration (max) 2.4 Gs
Operating Temperature (max) 55 deg C
Operating Temperature (min) 5 deg C
Nonoperating Temperature (max) 70 deg C
Nonoperating Temperature (min) -40 deg C
Acoustical
Nonrecoverable Read Errors 1 per 10^16 bits read
Supports S.M.A.R.T.Yes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 04X1DR 4X1DR

Weight: 1

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new & sealed in retail box packaging.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
