Boxx Technologies Render Farm 10100

Boxx Technologies Part #/MPN: 10100

DiscTech Item #: BOX-10100-RF-OE


$499.00
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$499.00

Interface Types: SATA, Ethernet RJ45, PCIe, Riser

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 8GB

Bays/Ports/Slots: 2

U Height: 4U

Boxx Technologies RenderBOXX Render Farm 10100 Series Blade - Refurbished

Boxx Technologies RenderBOXX Render Farm 10100 Series Blade - Refurbished

renderBOXX is purpose-built to power render-intensive 3D graphics and animation workflows. Featuring Intel® Xeon® processors, a single renderBOXX is the ultimate cornerstone for your render farm. Ten modules fit into a 4U (7”x19”) space, while IPMI 2.0 technology featuring KVM over IP enables the industry’s most efficient and flexible management of your render farm network.

Model configuration includes:

  • CPU: 4x Quad Core  Intel Xeon E5335 Processors
  • Memory: 8GB DDR2 667 ECC
  • HDD: 2x 80GB 7.2K SATA drives
  • Quad (4) sockets Intel 64-bit Xeon Support, 667 / 1066 / 1333MHz FSB
  • Intel 5000P (Blackford) Chipset
  • Up to 32GB DDR2 667 SDRAM Fully Buffered DIMM (FB-DIMM)
  • 2 x Intel (ESB2/Gigabit) 82563EB Dual-port Gigabit Ethernet Controller
  • 4 x SATA 3.0Gbps Ports via ESB2 Controller
  • 2 x (x8) PCI-Express expansion slots
  • 2 x ATI ES1000 Graphics with 16MB video memory
  • 2 x SIMSO IPMI 2.0 (Intelligent Platform Management Interface v.2.0, v.1.5)

Operating System:
Module System O/S Windows XP Professional Edition with SP3 ( x 2 )

CPU:
Quad Core Intel Xeon E5335 (R) Processsors

Memory:
8GB FBDIMM DDR2 667 REG ECC (8 -1GB FBDIMMS)

Hard Drives:
80GB 7200rpm Module System Drive (2 x 80GB SATA) (R)

Model Specifications:

  • Quad (4) sockets Intel 64-bit Xeon Support, 667 / 1066 / 1333MHz FSB
  • Intel 5000P (Blackford) Chipset
  • Up to 32GB DDR2 667 SDRAM Fully Buffered DIMM (FB-DIMM)
  • 2 x Intel (ESB2/Gigabit) 82563EB Dual-port Gigabit Ethernet Controller
  • 4 x SATA 3.0Gbps Ports via ESB2 Controller
  • 2 x (x8) PCI-Express
  • 2 x ATI ES1000 Graphics with 16MB video memory
  • 2 x SIMSO IPMI 2.0 (Intelligent Platform Management Interface v.2.0, v.1.5)

Click here to view the manufacturer's item description/brochure

Weight: 30 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
