Dell 30HYT Kioxia KCD8XVUG800G CD8-V Series 800GB 2.5" TLC PCIe 4.0 Mixed Use NVMe 1.4 U.2 SSD
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 800GB |
| Speed: | Solid State |
| Interface Types: | NVMe U.2 |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Mixed Use / MU |
| Electrical Interface: | PCIe 4.0 32GBps |
Description
Dell 30HYT Kioxia KCD8XVUG800G CD8-V Series 800GB 2.5" TLC PCIe 4.0 Mixed Use NVMe 1.4 U.2 SSD - Brand New OEM
Dell 30HYT Kioxia KCD8XVUG800G CD8-V Series 800GB 2.5" TLC PCIe 4.0 Mixed Use NVMe 1.4 U.2 SSD - Brand New OEM
The KIOXIA CD8-V Series is a Mixed Use data center NVMe™ SSD that is optimized to support a broad range of scale-out and cloud applications, including big data/IoT, online transaction processing, and virtualization.
Built with a PCIe® 4.0 (16 GT/s x4) interface, the CD8-V Series SSDs deliver consistent performance up to 1,250K IOPS (random read) and 200K IOPS (random write). Featuring KIOXIA 112-layer BiCS FLASH™ 3D TLC flash memory, the CD8-V 2.5-inch form factor SSDs deliver 3 DWPD (Drive Writes Per Day) of endurance making them well-suited for hyperscale data center applications.
Key Features
- PCIe® 4.0, NVMe™ 1.4 specification compliant
- Open Compute Project Datacenter NVMe™ SSD specification v2.0 support (not all requirements)
- Form factor: 2.5-inch, 15mm thickness
- Proprietary KIOXIA architecture: controller, firmware and 112-layer BiCS FLASH™ 3D TLC
Key Applications
- Hyperscale
- IoT and big data analytics
- Online transaction processing (OLTP) (transactional and relational databases)
- Virtualized environments
- Streaming media and content delivery networks
Compatibility
This drive is compatible with any server that accepts 2.5"x15mm (SFF Hard Drive) NVMe PCIe drives.
Specifications
| Specification | 800 GB |
|---|---|
| Base Model Number | KCD8XVUG800G |
| SIE Model Number | |
| SED Model Number | |
| Capacity | 800 GB |
| Form Factor | 2.5-inch, 15mm thickness |
| Interface | PCIe® 4.0, NVMe™ 1.4 |
| Maximum Interface Speed | 64 GT/s (PCIe® Gen4 x4) |
| Flash Memory Type | BiCS FLASH™ TLC |
| Sustained 128 KiB Sequential Read | 7,200 MB/s |
| Sustained 128 KiB Sequential Write | 1,800 MB/s |
| Sustained 4 KiB Random Read | 1,000K IOPS |
| Sustained 4 KiB Random Write | 80K IOPS |
| Power Consumption (Active) | 11 W typ. |
| Power Consumption (Ready) | 5 W typ. |
| Supply Voltage | 12 V ± 10 %, 3.3 V ± 15 % |
| MTTF | 2,500,000 hours |
| Warranty | 5 years |
| DWPD | 1 |
| Thickness | 15 mm +0 / -0.5 mm |
| Width | 69.85 mm ± 0.25 mm |
| Length | 100.45 mm Max |
| Weight | 130 g Max |
| Temperature (Operating) | 0 ℃ to 75 ℃ |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 30HYT 030HYT
Weight: 1 lb
Warranty: 1 Year DiscTech
Condition
The product is brand new.
Warranty
1 Year DiscTech Warranty
