Dell Part #/MPN: R730XD
DiscTech Item #: DEL-PER730XDSH16-E52698V4-RF-2M-TEMP
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:2 Month DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Interface Types: SAS Serial Attached SCSI, SATA, USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45, PCIe, VGA, Serial RS-232 DB9, SFF-8482
Form Factor: 2.5inx15mm SFF Server Drive
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
Bays/Ports/Slots: 26
U Height: 2U
Voltage: 110-240V Multi
Compatible Systems: Dell 13th Gen. R730/T630
Includes:
- Single Xeon E5-2640v3 2.6GHz 8-Core CPU (2nd CPU optional)
- 16GB ECC PC4 RDIMM RAM
- 26 SFF 2.5" Hotswap bays (24x front, 2x Rear Flexbay)
- H330 RAID Controller
- 4x 1GbE Ethernet RJ45
- Single 750W 100-240V (Worldwide compatible) AC Redundant x1 Power Supply (2nd Power Supply Optional)
- Rackable 2U Server
- Diskless system - HARD DRIVES & TRAYS are optional (Trays DP/N: G176J or 8FKXC) please add to order as separate line item(s). Add up to 8-units of 2.5" Enterprise SATA or SAS Drives & Trays to this system. Please call or email for assistance.
- Rails, keyboard, operating system and mouse are optional.
| UPGRADE OPTIONS | |
| Processor | 2nd Xeon E5-2640 v3 2.6GHz Processor |
| Memory / RAM | DDR4 RDIMM Options |
| Hard Drives / SSDs | 2.5" Enterprise Dell SAS / SATA Drives & SSDs |
| Power Supply | Additional 750W PSU |
| Rail Kit | Sliding ReadyRails |
| H730 Integrated Mini Mono 1GB RAID Controller | H730 Mini Mono 1GB RAID Controller |
| H730p Integrated Mini Mono 2GB RAID Controller | H730p Mini Mono 2GB RAID Controller |
Compatibility: Microsoft® Windows Server® 2008 R2
Microsoft Windows Server 2012
Microsoft Windows Server 2012 R2
Microsoft Windows Server 2016
Novell®
SUSE®
Linux Enterprise Server
Red Hat®
Enterprise Linux®
VMware®
ESX®
Virtualization options:
Microsoft Windows Server 2012 R2 with
Hyper-V
Citrix®
XenServer®
VMware vSphere ESXi
For more information on the specific versions
and additions, visit Dell.com/OSsupport.
- Single Xeon E5-2640v3 2.6GHz 8-Core CPU (2nd CPU optional)
- 16GB ECC PC4 RDIMM RAM
- 26 SFF 2.5" Hotswap bays (24x front, 2x Rear Flexbay)
- H330 RAID Controller
- 4x 1GbE Ethernet RJ45
- Single 750W 100-240V (Worldwide compatible) AC Redundant x1 Power Supply (2nd Power Supply Optional)
- Rackable 2U Server
- Diskless system - HARD DRIVES & TRAYS are optional (Trays DP/N: G176J or 8FKXC) please add to order as separate line item(s). Add up to 8-units of 2.5" Enterprise SATA or SAS Drives & Trays to this system. Please call or email for assistance.
- Rails, keyboard, operating system and mouse are optional.
Click here to view the manufacturer's item description/brochure
Alternate MPNs: PER730XD PER730XDSH16-E52640V3
Weight: 50 lb
Warranty: 2 Month DiscTech
