Dell W2JGY 1.92TB SAS SED TCG FIPS SSD RI 12Gbps For EMC PowerVault MD14 MD1400 MD1420 WUSTVA119BSS20
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 1.92TB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Read Intensive / RI |
| Electrical Interface: | SAS-3 12Gbps |
Description
Dell W2JGY 1.92TB 2.5" 12Gbps 512e Read Intensive SED TCG FIPS SAS SSD / Western Digital WUSTVA119BSS205 Ultrastar DC SS540 EMC PowerVault MD14 MD1400 MD1420 - Brand New
Ultrastar DC SS540 SAS SSD: Maximize Storage and Server Scalability
The Ultrastar® DC SS540 is Western Digital's 6th generation SAS SSD, designed to meet the ever-increasing data demands of modern data centers. Leveraging 96-layer 3D TLC NAND flash technology and a 12 Gb/s SAS interface, this SSD delivers exceptional performance, reliability, and capacity for mission-critical applications.
Key Features and Benefits
- High Performance: Achieve up to 470K/240K Random Read/Write IOPS for ultra-fast data access.
- Wide Range of Capacities: Available from 800GB to 15.36TB to suit diverse storage needs.
- Enhanced Reliability: Features a 0.35% AFR (2.5M hours MTBF), power-loss data management, and T10 end-to-end data protection.
- Security Features: Self-encrypting drive models conform to TCG's Enterprise specifications, with FIPS 140-2 validation for government applications.
- Flexible Power Options: Choose from 9, 11, and 14 Watt options to optimize power consumption.
- Dual-Port SAS Interface: Ensures seamless integration into data center environments with enhanced reliability.
- Endurance Options: Available in 1 and 3 drive writes per day (DW/D) to meet varying workload requirements.
Target Applications
- Ultra-high performance tier-0 enterprise storage
- Enterprise-class servers and high-performance computing (HPC)
- Software-defined storage (SDS)
- Online transaction processing (OLTP)
- Finance and e-commerce
- Database analytics
Why Choose Ultrastar DC SS540?
The Ultrastar DC SS540 offers a compelling combination of performance, capacity, and reliability, backed by Western Digital's decades of expertise in enterprise storage. It provides a cost-effective solution for data centers seeking to meet escalating demands for speed, endurance, and data protection. Trust Ultrastar SAS SSDs to optimize your storage systems and drive your business forward.
Compatibility
This drive is compatible with any server that accepts 2.5in x 15mm (SFF) SAS drives.
Specifications
| Model Number | W2JGY |
| Capacity | 1.92TB |
| Endurance | 1DW/D |
| Max Terabytes Written (TBW) | 1880 |
| Interface | SAS 6 / 12Gb/s |
| Form Factor | 2.5-Inch 15mm SFF |
| Flash Memory Technology | 3D TLC NAND |
| Read Throughput (max MiB/s, Sequential 128KiB) | 1,985 |
| Write Throughput (max MiB/s, Sequential 128KiB) | 1,024 |
| Read IOPS (max, Random 4KiB) | 237,000 |
| Write IOPS (max, Random 4KiB) | 88,133 |
| Mixed IOPS (70/30 R/W, max, 4KiB) | 142,959 |
| Read/Write Latency⁴ (μs, avg) | 140/90 |
| Unrecoverable Bit Error Rate (UBER) | 1 in 10¹⁷ |
| MTBF (M hours) | 2.5 |
| Annualized Failure Rate⁵ (AFR) | 0.35% |
| DWPD | 1 |
| Requirement (+/- 5%) | +5 VDC, +12VDC |
| Operating Modes (W, typical) | 9, 11, 14 |
| Idle (W, max) (Projected) | 3.7W |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 70.1mm |
| Length | 100.45 mm |
| Weight | 175 g Max. |
| Temperature (Operating) | 0 to 70 °C |
| Non-operating Temperature | -40°C to 80°C |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: W2JGY 0W2JGY 0B42809
Weight: 0.7 lb
Warranty: 1 Year DiscTech
