Hitachi HUH721212ALN600 0F30141 12TB SATA 4Kn 7.2k 6Gbps Hard Drive
- Brand NewCondition Levels Explained
The product is brand new.
- In Stock:60Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 5 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 12TB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 600 - 6Gbps |
| RAM: | 256MB |
Description
Hitachi UltraStar He12 HUH721212ALN60Y 12TB / 12,000GB 3.5" 6.0 Gb/s 7200 RPM 4K Native Serial Attached Technology Attachment Hard Disk Drive with Instant Secure Erasure - Brand New
More Value to the Data Center with Maximum Capacity, Power Efficiency and Reliability
Laying the foundation for a worry-free data center, HGST delivers capacity to conquer the data explosion – Ultrastar® He12 HDD. Designed to handle workloads up to 550TB per year, the Ultrastar He12 HDD is the industry’s first 12TB drive and uses PMR technology to make it drop-in ready for any enterprise-capacity application or environment. The stable internal environment created by fourth-generation HelioSeal® technology enables a new 8-disk design, increasing the capacity by 20% when compared to the 7-disk design of the prior generation. This highest capacity helium drive offers the lowest power profile in the industry to help data center architects meet eco-environmental goals and requirements. Targeted at 2.5M hours MTBF, the Ultrastar He12 HDDprovides the highest reliability rating available of all HDDs on the market today by building on the successful design of it’s 10TB, 8TB and 6TB predecessors. Trust HGST and the Ultrastar He12 HDD to deliver more capacity, more efficiency, more reliability and more value to your data center
Data Durability and Data Security to Support Compliance and Privacy Requirements
As drive capacity grows beyond single-digit TBs, object storage systems with erasure coding provide better data durability compared to RAID systems, given its tolerance for simultaneous error conditions. The Ultrastar He12 HDD is a best-fit for object storage implementations with its massive capacity and industry-leading reliability rating. Compliance and privacy requirements drive the need for increased data security. The Ultrastar He12 HDD offers security and encryption options to help protect data from unauthorized use, including TCG options on both SATA and SAS models.
HGST Quality and Service
The Ultrastar He12 HDD extends HGST’s long-standing tradition of reliability leadership with a 2.5M-hour MTBF rating and a 5-year limited warranty. Ultrastar quality, capacity, power efficiency, and world-class technical support and service provides customers with a lower total cost of ownership over previous generations. HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of HDD, SSD and systems to help the world harness the power of data.
Highlights
- 12TB capacity1 in a standard 3.5-inch form factor
- PMR technology works with all capacity enterprise applications & environments
- Reliable, field-proven, 4th generation design
- Industry’s best power efficiency (Watts/TB)
- Compared to 8TB air drives
- 50% more capacity
- 54% more power efficient (Watts/TB)
- 25% more reliable
- SATA 6Gb/s and SAS 12Gb/s
- 12Gb/s SAS compatible with next gen data centers; backwards compatible with 6Gb/s SAS
- 2.5M hours MTBF rating
- Instant Secure Erase (ISE) & Self-Encrypting Drive (SED) options
- Advanced Format 4Kn and 512e models
Applications/Environments
- Enterprise and data center applications where capacity density, power efficiency and reliability are paramount
- Cloud & Hyperscale storage
- Massive scale-out (MSO), high-density data centers
- Distributed File Systems
- Bulk storage using object storage solutions like CEPH™ and OpenStack Swift
- Primary and secondary storage for Hadoop® to support Big Data Analytics
- Centralized video surveillance
- Ideal for all mainstream enterprise capacity applications
Compatibility:
This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.
Specifications
| Ultrastar He^12 | |
|---|---|
| Model No | HUH721212ALN600 |
| CONFIGURATION | |
| Interface | SATA 6Gb/s |
| Capacity | 12TB / 12000GB |
| Format Sector Size (bytes) | 4Kn: 4096 |
| Max. Areal density (Gbits/sq. in) | 864 |
| PERFORMANCE | |
| Data buffer (MB) | 256 |
| Rotational Speed | 7200 |
| Latency average (ms) | 4.16 |
| Interface transfer rate ((MB/s, max) | 600 |
| Sustaned transfer rate MiB/s, typical )MB/s, typical) | 243 255 |
| Seek time (read/write, ms typical) | 8.0/8.6 |
| RELIABILITY | |
| Error rate (non-recoverable, bits read) | 1 in 10^15 |
| Load/Unload cycles (at 40°C) | 600,000 |
| Availability (hrs/day x days/wk) | 24x7 |
| MTBF | 2.5 |
| Annualized Failure Rate (AFR) | 0.35% |
| ACOUSTICS | |
| Idle (Bels, typical) | 2.0/3.6 |
| POWER | |
| Requirement | +5 VDC, +12VDC d |
| Operating (W) | 7.2 |
| Idle (W) | 5.3 |
| Power consumption efficiency at idle (W/TB) | |
| (Watts/TB) | 0.44 |
| (Watts/GB) | 0.00044 |
| PHYSICAL SIZE | |
| z-height (mm) | 26.1 |
| Dimensions (width x depth, mm) | 101.6(+/-0.25)x147 |
| Weight(g,max) | 660 |
| ENVIRONMENTAL (OPERATING) | |
| Ambient temperture | 5° to 60°C |
| Shock(half-sine wave 2 ms, G) | 70 |
| Vibration(G RMS 5 to 500 Hz) | 0.67(XYZ) |
| ENVIRONMENTAL (NON-OPERATING) | |
| Ambient temperature | -40° to 70°C |
| Shock(half-sine wave 2 ms, G) | 33(2ms)/150(11ms) |
| Random vibration (G RMS 2 to 200 Hz | 1.04 (XYZ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUH721212ALN600
Weight: 1.8 lb
Warranty: 5 Year Manufacturer
Condition
Brand New
Warranty
5 Year Manufacturer Warranty
