OCZ ZD-XL SQL Accelerator ZDXRPFC8MT320-3200 3.2TB PCIe SSD

OCZ Technology Part #/MPN: ZDXRPFC8MT320-3200

DiscTech Item #: OCZ-ZDXRPFC8MT320-3200-BN-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Capacity: 3.2TB

Speed: Solid State Memory

Interface Types: PCIe

Form Factor: Full-Height/Half-Length

Encryption/SED Supported

Sector Size: 512 / 512e

Electrical Interface: PCIe - v2.0 - 8GBps


OCZ ZD-XL SQL Accelerator ZDXRPFC8MT320-3200 3.2TB / 3200GB PCIe 2.0 MLC Full-Height/Half-Length Self Encrypting Solid State Drive - Brand New


ZD-XL 3.2 SQL Accelerator is a tightly integrated hardware/software, plug-and- play acceleration solution optimized for Microsoft SQL Server applications. It leverages OCZ’s industry-proven PCIe SSD hardware and application-tuned software to deliver low latency flash that resolves potential SQL Server bottleneck issues enabling the flash to be deployed as a local flash volume, a flash cache for HDD volumes, or as a combination of both. The solution includes a combination of fast flash performance, a unique cache mechanism that makes advanced and statistically-optimized decisions on what data to cache, and a dynamic cache warm-up scheduler that enables workloads to be placed on flash cache in advance of demanding and critical jobs.


Compatible with PCIe 2.0 slots.

Physical Specifications
Usable Capacities (IDEMA)3200GB
NAND ComponentsMulti-Level Cell (MLC)
InterfacePCIe Gen 2 x8
Form FactorFull-Height/Half-Length (FH/HL)
Storage ControllerVCA 2.0 (Virtualized Controller ArchitectureTM)
Dimenstions (L x W x H)126.3mm x 180.9mm x 21.6mm
Sustained Performance
Max ReadUp to 2,900 MB/s
Max WriteUp to 2,200 MB/s
Sustained Random 4K
- Reads
- Writes

- Up to 252,000 IOPS
- Up to 76,000 IOPS
Sustained Random 8K
- Reads
- Writes

- Up to 155,000 IOPS
- Up to 31,000 IOPS
Power Consumption3200GB: 20W Idle, 22.8W Active
Operating Temperature0°C ~ 55°C
Non-Operating Temperature-45°C ~ 85°C
Airflow Requirements300LFM (Linear Feet per Minute) at 25°C
550LFM (Linear Feet per Minute) at 40°C
Certifications and DeclarationsRoHS, FCC , CE, BSMI, C-TICK, VCCI, KCC, UL
Mean Time Between Failures (MTBF)2 million hours
Endurance RatingMinimum of 2.5PB (3200GB)
Power Fail ProtectionFull in-flight data protection for unexpected system power loss
Data Path ProtectionEnd-to-end data path protection at every data juncture
Data ReliabilityRead Unrecoverable Bit Error Rate (UBER) 10^17
Data EncryptionData compression, Data de-duplication, and AES 128bit encryption
Product Health MonitoringSelf-Monitoring, Analysis and Reporting Technology (SMART) Support with enterprise attributes
Data RecoveryIn case of block failures, RAID mechanisms are used to recover data

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
