Sun X5244A / 540-4689 SCSI Hard Drive


DiscTech Item #: SUN-540-4689-RF-OE

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Enterprise Grade

Capacity: 36GB

Speed: 10,000RPM

Interface Types: SCSI 80pin SCA-2 Hot-Swap

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 52 - 84.1

Average Seek Time: 4.5 / 5.0

Electrical Interface: SCSI LVD U320 - 320MBps 16-bit

On-Board Cache: 8MB

Sun 36.4 GB 10K U320 80pin SCA-2 SCSI Hard Drive 540-4689 / X5244A - Refurbished

Sun 36GB 10K U320 80pin SCA-2 SCSI Hard Drive 540-54689 / X5244A - Refurbished.

This drive is comaptible with the following Sun products:

Ultra 60, 80
Enterprise 250, 450, 220R, 420R
Sun Fire V1280, V120, V210, V240, V250
Netra 1280, Netra t1120/1125, t1400/1405, Netra ct 400/800, Netra st A1000, st D1000
StorEdge A1000, D1000, StorEdge MultiPack, StorEdge S1, D2, D240


The 540-4689 / X5244A is compatible with the following Sun equipment:

Workstations:Ultra 60, 80
Servers: Enterprise 250, 450, 220R, 120R, 420R
Sun Fire V1280, V210, V240, V250
Telco: Netra 1280
Netra t1120/1125, t1400/1405
Netra ct 400/800
Netra st A1000, st D1000
Disk Arrays: StorEdge A1000, D1000
StorEdge MultiPack
StorEdge S1, D2, D240

Model number 540-4689 / X5244A
Form Factor(width) 3.5-inch
Form Factor(height) 1-inch
Height 25.4 mm
Width 101.6 mm
Length 146.05 mm
Weight 0.709 kg
Formatted Capacity 36.74 Gbytes
Rotational Speed 10,025 rpm
External (I/O) Transfer Rate (max) 320 MBytes/sec
Average Seek Time, Read 4.5 msec typical
Average Seek Time, Write 5.0 msec typical
Track-to-Track Seek, Read 0.4 msec typical
Track-to-Track Seek, Write 0.6 msec typical
Average Latency 2.99 msec
Default Buffer (cache) Size 8 Mbytes
Number of Discs (physical) 2
Number of Heads (physical) 4
Acoustics, Idle (sound power, typ) 3.6 Bels

Click here to view the manufacturer's item description/brochure

Alternate MPNs: X5244A

Weight: 2 lb

Warranty: 1 Year DiscTech
