Western Digital Part #/MPN: WD2003FYYS
DiscTech Item #: WDC-WD2003FYYS-BN-OE-DEL
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 138
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 64MB
Western Digital RE4 WD2003FYYS 2000GB / 2TB 7.2K 64MB SATA Hard Drive - Brand New OEM
WD RE4 enterprise SATA hard drives combine 64 MB cache with dual processors and dual stage actuation for lightning-fast performance in demanding server and storage applications. Technologically advanced acoustics minimize noise. Cool drive operation and enhanced reliability features help protect the drive and the data stored on it.
Key Features
Massive capacity - WD RE4 Enterprise SATA drives are available with up to 2 TB's of cavernous capacity.
Dual actuator technology - A head positioning system with two actuators that improves positional accuracy over the data track(s). The primary actuator provides coarse displacement using conventional electromagnetic actuator principles. The secondary actuator uses piezoelectric motion to fine tune the head positioning to a higher degree of accuracy. (2 TB model only)
Dual processor - With double the processing power, WD RE4 boasts the highest performance of any drive in the WD RE family.
StableTrac - The motor shaft is secured at both ends to reduce system-induced vibration and stabilize platters for accurate tracking during read and write operations.
RAFF - Enhanced RAFF technology includes sophisticated electronics to monitor the drive and correct both linear and rotational vibration in real time. The result is a significant performance improvement in high vibration environments over the previous generation of drives.
IntelliSeek - Calculates optimum seek speeds to lower unnecessary power consumption, noise, and vibration.
Multi-axis shock sensor - Automatically detects the subtlest shock events and compensates to protect the data.
RAID-specific, time-limited error recovery (TLER) - Prevents drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.
Third generation dynamic fly height - Each read-write head's fly height is adjusted in real time for optimum reliability.
Thermal extended burn-in test - Each drive is put through extended burn-in testing with thermal cycling to ensure reliable operation.
NoTouch ramp load technology - The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Perpendicular Magnetic Recording (PMR) - WD RE4 drives utilize PMR technology to achieve even greater areal density, reliability, and design margin.
Active Power Save - Delivers best-in-class power consumption through advanced WD firmware that conserves power in active seek modes without degrading performance.
DPN: 2G4HM / 02G4HM
Compatibility:
This drive is compatible with all of our 3.5" SATA trays.
Specifications | |
---|---|
Model number | WD2003FYYS |
Model Name | RE4 |
Formatted Capacity | 2,000 Gbytes |
Rotational Speed | 7,200 |
Default Buffer (cache) Size | 64 Mbytes |
Performance | |
External (I/O) Transfer Rate (max) | 3 Gb/s |
Physical | |
Form Factor(width) | 3.5-inch |
Form Factor(height) | 1-inch |
Height | 26.1 mm |
Width | 101.6 mm |
Length | 147.0 mm |
Weight | 0.75 kg |
Electrical | |
Power (Typical) | 10.7 watts |
Power (Idle) | 8.1 watts |
Power (Standbye) | .185 watts |
Power (Sleep) | .185 watts |
Environmental | |
Max Operating Shock (2-msec) | 30 Gs |
Max Nonoperating Shock (2-msec) | 300 Gs |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 2G4HM 02G4HM WD2003FYYS-18W0B0
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
