Dell PowerEdge 2850 Server

(0) No Reviews Yet

Dell Part #/MPN: PE2850

DiscTech Item #: DEL-PE2850-UP-OE


Interface Types: SCSI 80pin SCA-2 Hot-Swap, Ethernet RJ45, PCI-X, PCIe, S-Video, SFF-8470

Electrical Interface: SCSI LVD U320 - 320MBps 16-bit

On-Board Cache: 2MB

Bays/Ports/Slots: 6

U Height: 2U

Processor type Dual 3.0GHz Intel® Xeon™ processors
Front-side bus speed 800 MHz
L2 cache1MB internal cache
Expansion Bus
Bus type PCI-X, PCI Express
Expansion slots via riser card cage:
PCI-Xone 3.3-V, 64-bit, 100-MHz or three 3.3-V, 64 bit, 133MHz
PCI Expressone x4 lane width

one x8 lane width
Architecture 144-bit ECC registered PC2-3200 DDR2 SDRAM DIMMs, with two-way interleaving, rated for 400-MHz operation
Memory module sockets Six 240-pin
SCSI hard drivesup to six 1-inch, internal, hot-plug, Ultra320 SCSI
Optical drive Internal CD-ROM drive
Externally accessible
NICTwo RJ-45 (for integrated 1-Gigabit NICs)
PS/2-style keyboard 6-pin mini-DIN
PS/2-compatible mouse 6-pin mini-DIN
Serial9-pin, DTE, 16550-compatible
USBTwo 4-pin, USB 2.0 compliant
Video 15-pin VGA
Video 15-pin VGA
USBTwo 4-pin, USB 2.0 compliant
Internally accessible
SCSI channelsTwo 68-pin U320 SCSI
Video type ATI Radeon 7000-M video controller; VGA connectors
Video memory 16 MB
AC power supply (per power supply)
Voltage84 -264 VAC, autoranging, 47-63 Hz, 10.1 A
Heat dissipation2388 BTU/hr maximum
Maximum inrush currentUnder typical line conditions and over the entire system ambient operating range, the inrush current may reach 25 A per power supply for 10 ms or less.
System batteryCR 2032 3.0-V lithium ion coin cell
ROMB battery (optional)4.1-V lithium ion
Height8.656 cm (3.40 in)
Width44.7 cm (17.6 in)
Depth75.68 cm (29.79in)
Weight (maximum configuration)26.76 kg (59 lb)
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 8% to 85% (noncondensing) with a maximum humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating0.25 G at 3–200 Hz for 15 min
Storage0.5 G at 3–200 Hz for 15 min
Maximum shock
OperatingOne shock pulse in the positive z axis (one pulse on each side of the system) of 41 G for up to 2 ms
StorageSix consecutively executed shock pulses in the positive and negative x, y, and z axes (one pulse on each side of the system) of 71 G for up to 2 ms
Operating–16 to 3048 m (–50 to 10,000 ft)
Storage–16 to 10,600 m (–50 to 35,000 ft)

Weight: 50 lb

Warranty: 2 Month DiscTech

Used Pull

Condition Levels Explained

The product has been removed from a working system (e.g. server). These products vary in their usage due to age of system & type of service etc.. However, Used System Pulls are fully tested and all handling is performed by trained technicians, taking full ESD precautions.

2 Month DiscTech Warranty
