Hitachi Part #/MPN: 17R6393
DiscTech Item #: HIT-17R6393-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 73GB
Speed: 10,000RPM
Interface Types: SCSI 68pin HD68
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 46.8 - 89.3
Average Seek Time: 4.3
Electrical Interface: SCSI LVD U320 - 320MBps 16-bit
On-Board Cache: 16MB
Hitachi 17R6393 / HUS103073FL3600 73GB 3.5in 10K RPM U320 68 Pin Enterprise Ultrastar 10K300 SCSI HDD- Brand New
Hitachi 17R6393 / HUS103073FL3600 73GB 3.5" 10000 RPM U320 68 Pin Enterprise Ultrastar 10K300 SCSI Hard Disk Drive - Brand New
Alt MPN: HUS103073FL3600
Lowest total cost of ownership - The Ultrastar™ 10K300 offers the lowest total cost of ownership enterprise solution in the industry. At double the capacity of previous generations, the new Ultrastar drive enables mission-critical confi gurations utilizing fewer systems for equivalent capacity and performance, requiring less power to run those systems, and fewer people to manage them. A mature drive design means higher quality and less downtime for repairs.
Highlights
- Proven drive design for superior quality and reliability
- 10,000 RPM rotational speed for outstanding performance
- Full range of capacities from an industry leading 300GB to 73GB offers enterprise customers configuration flexibility and ease of integration
- Ultra320 SCSI and 2Gb/s Fibre Channel supports high data throughput
Applications/Environments
- Online transaction processing
- RAID
- Storage Area Network (SAN)
- Network Attached Storage (NAS)
- Scientific engineering and data analysis
- Imaging systems
- Media streaming
- Data warehousing
Compatibility:
This drive is compatible with any server that accepts 3.5"x1.0" (LFF Hard Drive) SCSI Drives.
| Drive Model | 17R6393 |
|---|---|
| Standard Model | HUS103073FL3600 |
| SPECIFICATIONS | |
| Interface | 2Gb/s FCAL |
| Capacity | 73 GB |
| 512K Blocks | 143,374,805 |
| Sector Size (Variable, Bytes/Sector) | 512-524 (2 byte incr.) |
| Recording Zones | 18 |
| Data Heads (Physical) | 3 |
| Data Disks | 2 |
| Max. Areal Density (Gbits/sq. in) | 61 |
| PERFORMANCE | |
| Data Buffer | 16 MB |
| Rotational Speed | 10000 RPM |
| Latency Average | 2.99 ms |
| Media Transfer Rate(max) | 1075 mb |
| Interface Transfer Rate(max) | 200 MB/s |
| Sustained Transfer Rate (Typ.) | 46.8 - 89.3 MB/s |
| Seek Time (Read, Typical) | 4.3 ms |
| RELIABILITY | |
| Error Rate (Non-Recoverable, Bits Read) | 1 in 10e16 |
| Availability (hrs/day x days/wk) | 24 x 7 |
| ACOUSTICS | |
| Idle (Bels, Typical) | 3.4 |
| POWER | |
| Requirement | +5 VDC (+/-5%) +12 VDC (+/-5%) |
| Startup Current (A, Max) | 1.10 (5V), 2.45 (12V) |
| Idle | 10.3 W |
| Power Consump. Efficiency Index | 0.141 W/GB |
| PHYSICAL SIZE | |
| Z-Height (mm/in) | 26.1/1.0275 |
| Width (mm/in) | 101.85/4.009 |
| Depth (mm/in) | 147.0/5.787 |
| Weight (typical, g/lb max) | 750.0/1.653 |
| ENVIRONMENTAL (OPERATING) | |
| Ambient Temperature | 5° to 55° C |
| Shock (Half-Sine Wave) | 15G (11ms) |
| Vibration, Random (G RMS 5 to 500 Hz) | 1.0, All Axes |
| ENVIRONMENTAL (NON-OPERATING) | |
| Ambient Temperature | -40° to 70° C |
| Shock (Half-Sine Wave) | 250G (2ms), 75G (11ms) |
| Vibration, Random (G RMS 5 to 500 Hz) | 5.0, All Axes |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: HUS103073FL3600
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
