Synology Part #/MPN: RC18015xs-PLUS
DiscTech Item #: SYN-RC18015XS-PLUS-BN-5Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:5 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: PCIe
Form Factor: 3.5inx1.0in LFF Hard Drive
Encryption/SED Supported
Electrical Interface: Ethernet Gigabit - 1Gbps
On-Board Cache: 8GB
Wattage/VA: 150W
Voltage: 110-240V Multi
Synology RackStation RC18015xs+ SAS Quad Core Redundant AES-NI NAS Server - Brand New
Synology RackStation RC18015XS+ Network Attached Storage Server includes ...
- 2x USB 3.0 ports
- 1x Expansion port
- 4x Ethernet RJ45 1GbE LAN ports
- 1x PCIe 10GbE slot
- 8GB DDR3 ECC Ram, expandable up to 32GB (8GB X 4)
- Maximum 180-Bays with an expansion unit
- Intel Xeon E3-1230 v2 Quad Core 3.3 GHz CPU
- Accepts 3.5" and 2.5" SAS hard drives and 2.5" SAS solid state drives.
RackStation RC18015xs+
Uncompromising reliability, unyielding data protection
Featuring a high-availability design, next-generation snapshot technology, and massive scalability up to 180 drives, RC18015xs+ and RXD1215sas deliver the secure, reliable, and superior performance storage solution for enterprises seeking business continuity and point-in-time data recovery.
| SPECIFICATIONS | |
|---|---|
| Model Number | RC18015xs+/RC18015xs-PLUS |
| CPU | |
| CPU Model | Intel Xeon E3-1230 v2 |
| CPU Architecture | 64-bit |
| CPU Frequency | Quad Core 3.3 GHz |
| Floating Point | Yes |
| Hardware Encryption Engine (AES-NI) | Yes |
| MEMORY | |
| System Memory | 8 GB DDR3 ECC |
| Memory Module Pre-installed | 4 GB x 2 |
| Total Memory Slots | 4 |
| Memory Expandable up to | 32 GB (8 GB x 4) |
| STORAGE | |
| Maximum Drive Bays with Expansion Unit | 180 |
| Compatible Drive Type | |
| Maximum Raw Capacity with Expansion Units | 1440 TB (8 TB HDD x 180) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | |
| EXTERNAL PORTS | |
| USB 3.0 Port | 2 |
| Expansion Port | 1 |
| APPEARANCE | |
| Size (Height x Width x Depth) | 44 mm x 430 mm x 480 mm |
| Weight | 7.3 kg |
| OTHERS | |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| PCIe x8 Slot for 10Gbe/ 1Gbe Network Card | 1 (at x8 mode) |
| Wake on LAN/WAN | Yes |
| System Fan | 40 mm x 40 mm x 6 pcs |
| Fan Speed Mode | |
| Easy Replacement System Fan | Yes |
| Power Recovery | Yes |
| Noise Level | 48 dB(A) |
| Power Recovery | Yes |
| Scheduled Power On/Off | Yes |
| Power Supply Unit / Adapter | 2 x 150W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 HZ, Single Phase |
| Power Consumption | 60.16 W (Access) |
| British Thermal Unit | 205.27 BTU/hr (Access) |
| Redundant Power Supply (for xs+ and RP model) | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: RC18015xs+
Weight: 17 lb
Warranty: 5 Year Manufacturer
Brand New
The product is brand new.
5 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
