AMD Part #/MPN: OPTERON-6272
DiscTech Item #: AMD-OPTERON-6272-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: Socket G34
Electrical Interface: Clock 2.1 - 2.19 GHz
On-Board Cache: 16MB
Wattage/VA: 80W
AMD Opteron OPTERON-6272 2.1 GHz 16 Core 32MB L2 + L3 Cache Processor - Socket G34 - Brand New
AMD Opteron OPTERON-6272 2.1 GHz 16 Core / HexaDeca-Core 32MB L2 + L3 (16MB L2 / 16MB L3) Cache Processor - Socket G34 - Brand New
Alt Model#: OS6272WKTGGGU, OS6272WKTGGGUWOF
IBM / Lenovo Model#: 90Y5374
AMD proudly presents the new AMD Opteron 6200 Series—the world’s first and only 16-core x86 server processor with the highest core density for incredible scalability to handle demanding multi-threaded workloads such as cloud computing, virtualization, high-performance computing (HPC), databases and business applications.
The innovative modular architecture helps pack in more cores, making it the natural choice for heavy-threaded cloud computing environments and enterprise applications that demand outstanding performance and scalability.
- NEW CORE ARCHITECTURE DRIVES MORE CORE DENSITY AND GREATER THROUGHPUT -The modular design features up to 33% more cores and 35% greater performance in a smaller silicon footprint than AMD’s current products, bringing high performance throughput for scalable computing environments like virtualization, HPC, web/cloud clusters and database applications. AMD has designed several new features, including AMD Turbo CORE technology, ISA Enhancements and Flex FP, into its processors so that datacenters can maximize their performance potential.
- AMD TURBO CORE TECHNOLOGY - AMD Turbo CORE Technology allows processors to independently boost their clock speeds, scaling frequency up 500MHz-1GHz automatically to respond to the need for more application performance.
- AMD-P 2.0 - The AMD-P suite of energy-efficient technologies helps customers maximize the performance per watt in their datacenter and can help lower power and cooling costs. TDP Power Cap allows user to set the maximum processor power ceiling via BIOS or APML to meet power and workload demands. C6 Power State reduces processor power consumption at active idle by up to 37% while AMD CoolSpeed Technology protects processor integrity by reducing power-states, when a temperature limit is reached. Other features include C1E, LV-DDR3 support and APML (Advanced Platform Management Link) which provides an interface for processor and systems management monitoring and controlling of system resources (in APML-enabled platforms).
- HYPERTRANSPORT 3.0 TECHNOLOGY WITH HT ASSIST - HyperTransport Technology (HT or HTT) is a high-speed, low latency, point-to-point link designed to increase communication speeds between integrated circuits in computers, servers, embedded systems, and networking and telecommunications equipment. HT 3.0 technology offers the processor up to a maximum 6.4GT/s interconnect rate. HT Assist helps to increase coherent memory bandwidth and reduce latency in multi-node systems by reducing cache probe traffic between cores, resulting in faster queries that can increase performance for cache sensitive applications such as database, virtualization, and compute intensive applications.
- QUAD CHANNEL MEMORY SUPPORT - The AMD Opteron 6200 Series supports quad-channel memory (U/RDDR3, ULV RDDR3 and LRDIMM) that delivers up to 102.4 GB/s memory bandwidth per CPU for Socket G34 for increased performance especially in memory-intensive workloads. LR-DIMMs provide more capacity per DIMM, which can enable higher overall server memory configurations. Virtualization, cloud computing and other high-capacity applications greatly benefit from LR-DIMMs.
- AMD VIRTUALIZATION (AMD-V) 2.0 -AMD Virtualization (AMD-V) is a set of unique on-chip features that help AMD processor-based servers and clients run multiple operating systems and applications on a single machine by improving the efficiency of virtualization software. AMD Virtualization (AMD-V) Technology 2.0 heightens virtualization efficiency with new enhancements to the AMD-V suite of virtualization to optimize data center rack space and help minimize management tasks.
AMD Opteron 6272 | |
---|---|
Model Number | OPTERON-6272 |
Alt Model Number | OS6272WKTGGGU OS6272WKTGGGUWOF |
IBM Model Number | 90Y5374 |
General information | |
Type | CPU / Microprocessor |
Market segment | Server |
Family | AMD Opteron 6200 series |
Frequency | 2100 MHz |
Maximum turbo frequency | |
Bus speed | 3200 MHz HyperTransport links (6.4 GT/s per link) |
Package | 1944-land lidded organic Land Grid Array (LGA) |
Socket | Socket G34 |
Architecture / Microarchitecture | |
Microarchitecture | Bulldozer |
Platform | Maranello |
Processor core | Interlagos |
Core stepping | OR-B2 |
CPUID | 600F12 |
Manufacturing process | 0.032 micron silicon-on-insulator (SOI) technology |
Die | 316mm |
Data width | 64 bit |
The number of CPU cores | 16 |
The number of threads | 16 |
Floating Point Unit | Integrated (shared between two cores in each module) |
Level 1 cache size | |
Level 2 cache size | 8 x 2 MB 16-way set associative shared exclusive caches |
Level 3 cache size | 2 x 8 MB up to 64-way set associative shared caches |
Cache latency | 3 (L1 cache) |
Multiprocessing | Up to 4 processors |
Features | |
Low power features | AMD-P 2.0: |
Integrated peripherals / components | |
Integrated graphics | None |
Memory controller | |
Other peripherals | HyperTransport 3.0 technology with 4 HT links |
Electrical / Thermal parameters | |
Maximum operating temperature | 55°C - 69°C |
Average CPU Power | 80 Watt |
Thermal Design Power | 115 Watt |
ROHS Compliant
Alternate MPNs: 90Y5374 OS6272WKTGGGU OS6272WKTGGGUWOF
Weight: 1 lb
