Apacer SM210-M280-256GB / Dell 3W6PG / APM2T80SM21256GVNS-1KTMGW / 256GB SATA M.2 2280 6Gbps SSD
| Capacity: | 256GB |
| Speed: | Solid State |
| Interface Types: | SATA M.2 NGFF |
| Form Factor: | M.2 x 80mm |
| SSD Endurance DWPD: | Consumer / Value |
| Electrical Interface: | SATA 600 - 6Gbps |
Description
Apacer SM210-M280-256GB / Dell 3W6PG / APM2T80SM21256GVNS-1KTMGW / 256GB SATA M.2 2280 6Gbps NAND SSD - Brand New
Apacer SM210-M280-256GB / Dell 3W6PG / 256GB SATA M.2 2280 6Gbps NAND SSD - Brand New
Alt P/Ns: 03W6PG / APM2T80SM21256GVNS-1KTMGW
Overview
SM210-M280 is the next generation modularized Solid State Drive (SSD) with the shape of M.2 form factor, aimed to be the more suitable for laptop and server with standard width at only 22.00 mm. SM210-M280 appears in M.2 2280 mechanical dimensions and is believed to be the leading add-in storage solution for future host computing systems. The M.2 SSD is designed with SATA-based connector pinouts, providing full compliance with the latest SATA Revision 3.2 interface specifications. Aside from SATA compliance, SM210-M280 delivers exceptional performance and power efficiency. Regarding reliability, SM210-M280 is built with a powerful SATA controller that supports on-the-module ECC as well as efficient wear leveling scheme. In terms of power efficiency, SM210-M280 is compliant with SATA 6.0 Gbps interface standard so that it can operate on SATA power management modes, which greatly save on power consumption.
Features
- SATA 3 (6Gbps) interface
- M.2 (NGFF) Connector
- Global wear-leveling and block management
- Built-in ATA secure erase and S.M.A.R.T. functions
- Single side design
Compatibility:
This drive is compatible with PCs, Laptops and other devices that accept M.2 2280 SATA drives
Specifications
Specifications
| SM210-M280 | |
|---|---|
| Model | SM210-M280-256GB |
| Interface | SATA 3.0 (6Gb/s) |
| Connector | M.2 B & M key |
| Form Factor | 2280 |
| NAND Flash Type | MLC |
| Capacity | 256GB |
| External DRAM | Yes |
| Sustained Read Performance (MB/sec) | Up to 510 |
| Sustained Write Performance (MB/sec) | Up to 475 |
| ECC Engine | Built-in up to 40-bit per 1K bytes BCH ECC |
| IOPs (4K Random Write) | 45K |
| Standard Operating Temperature ( °C ) | 0 ~ + 70 |
| Extended Operating Temperature ( °C ) | -40 ~ + 85 |
| Storage Temperature ( °C ) | -40 ~ + 100 |
| Thermal Sensor | Optional |
| Shock | Operation: 50G, 11ms Non-operation: 1500G, 0.5ms |
| Vibration | Operation: 7.69 Grms, 20~2000 Hz/random (compliant with MIL-STD-810G) Non-operation: 15G, 10 ~ 2000 Hz/sine |
| Operating Voltage | 3.3 V ± 5% |
| Power Consumption | Active mode: 745 mA & Idle mode: 75 mA |
| Dimension (L x W x H ) | Single side: 80.00 x 22.00 x 2.23 (mm) Double side: 80.00 x 22.00 x 3.58 (mm) |
| MTBF (hours) | >1,000,000 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 3W6PG 03W6PG APM2T80SM21256GVNS-1KTMGW
Weight: 0.25 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
