Part #/MPN: SM210-M280
DiscTech Item #: APA-SM210-M280-BN-OE-DEG
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:4Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Capacity: 512GB
Speed: Solid State Memory
Interface Types: SATA, SATA M.2 NGFF
Form Factor: M.2 x 80mm
Sector Size: 512 / 512e
Sustained Throughput: 1700/1400
Electrical Interface: SATA 300 - 3.0Gbps
SSD Type: TLC
SSD Endurance DWPD: Consumer / Value
Apacer SM210-M280 / Dell 8V54G 512GB SATA M.2 2280 6Gbps NAND MLC SSD - Brand New
Apacer SM210-M280 / Dell 8V54G 512GB Serial ATA M.2 80 x 22mm NGFF 2280 6Gbps NAND MLC Solid State Drive - Brand New
Alt P/Ns: 08V54G / APM2T80SM21512GFDD-1KTMGW
OverviewSM210-M280 is the next generation modularized Solid State Drive (SSD) with the shape of M.2 form factor, aimed to be the more suitable for laptop and server with standard width at only 22.00 mm. SM210-M280 appears in M.2 2280 mechanical dimensions and is believed to be the leading add-in storage solution for future host computing systems. The M.2 SSD is designed with SATA-based connector pinouts, providing full compliance with the latest SATA Revision 3.2 interface specifications. Aside from SATA compliance, SM210-M280 delivers exceptional performance and power efficiency. Regarding reliability, SM210-M280 is built with a powerful SATA controller that supports on-the-module ECC as well as efficient wear leveling scheme. In terms of power efficiency, SM210-M280 is compliant with SATA 6.0 Gbps interface standard so that it can operate on SATA power management modes, which greatly save on power consumption.
Features- SATA 3 (6Gbps) interface
- M.2 (NGFF) Connector
- Global wear-leveling and block management
- Built-in ATA secure erase and S.M.A.R.T. functions
- Single side design
Compatibility:
This drive is compatible with servers and arrays that accept M.2 2280 SATA drives
| SM210-M280 | |
|---|---|
| Model | SM210-M280 |
| Interface | SATA 3.0 (6Gb/s) |
| Connector | M.2 B & M key |
| Form Factor | 2280 |
| NAND Flash Type | MLC |
| Capacity | 32GB~256GB |
| External DRAM | Yes |
| Sustained Read Performance (MB/sec) | Up to 510 |
| Sustained Write Performance (MB/sec) | Up to 475 |
| ECC Engine | Built-in up to 40-bit per 1K bytes BCH ECC |
| IOPs (4K Random Write) | 45K |
| Standard Operating Temperature ( °C ) | 0 ~ + 70 |
| Extended Operating Temperature ( °C ) | -40 ~ + 85 |
| Storage Temperature ( °C ) | -40 ~ + 100 |
| Thermal Sensor | Optional |
| Shock | Operation: 50G, 11ms Non-operation: 1500G, 0.5ms |
| Vibration | Operation: 7.69 Grms, 20~2000 Hz/random (compliant with MIL-STD-810G) Non-operation: 15G, 10 ~ 2000 Hz/sine |
| Operating Voltage | 3.3 V ± 5% |
| Power Consumption | Active mode: 745 mA & Idle mode: 75 mA |
| Dimension (L x W x H ) | Single side: 80.00 x 22.00 x 2.23 (mm) Double side: 80.00 x 22.00 x 3.58 (mm) |
| MTBF (hours) | >1,000,000 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 8V54G 08V54G APM2T80SM21512GFDD-1KTMGW
Weight: 0.25 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
