Apple Xserve Xeon A1196 Quad Core

APPLE Part #/MPN: A1196

DiscTech Item #: APL-A1196-RF-OE


Interface Types: SAS Serial Attached SCSI, SATA, Firewire IEEE1394 iLink, USB 2.0, Ethernet RJ45, PCI-X, PCIe, SVGA, Serial RS-232 DB9

Electrical Interface: Ethernet Gigabit - 1Gbps

On-Board Cache: 4MB

Bays/Ports/Slots: 4

Apple Xserve Xeon A1196 2.66GHz Quad Core Rack Server - No Drives Included - Refurbished

Apple Xserve Xeon A1196 2.66GHz Quad Core Rack Server

Note: There are no drives included with this server.


  • Processors - 2x Dual Core Xeon 5150 (4 Cores total)
  • Processor Speed - 2.66GHz
  • Frontside bus - 1.33GHz frontside bus per processor
  • L2 cache - 4MB shared L2 cache per processor
  • Memory - Up to 32GB of ECC FB-DIMM memory using pairs of 512MB, 1GB, 2GB, or 4GB memory modules
  • Hot-plug storage - Any combination of SATA or SAS Apple Drive Modules
  • Internal RAID - Xserve RAID card with 256MB RAID cache, hardware RAID 0,1 and 5 and integrated 72-hour cache battery backup; supports internal SATA or SAS drives

  • Click here to view the manufacturer's item description/brochure

    Weight: 40 lb

    Warranty: 1 Year DiscTech


Condition Levels Explained

The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
