Avocent AV3108-001 8-Port 1U KVM IP Switch

Avocent Part #/MPN: AV3108-001

DiscTech Item #: AVO-AV3108-001-BN-2Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: USB 2.0, Ethernet RJ45, VGA

Electrical Interface: Ethernet Fast - 100Mbps

Bays/Ports/Slots: 8

U Height: 1U

Wattage/VA: 18W

Voltage: 110-240V Multi

Avocent AV3108-001 8-Port 1U Rackmount KVM Over IP Switch with CAC & Local or Remote Access - Brand New

Avocent AV3108-001 8-Port 1U Rackmount KVM / Kernel-based Virtual Machine Over IP / Internet Protocol Switch with CAC / Common Access Card & Local or Remote Access - Brand New

Avocent AV 3108 KVM over IP Switch

Built for small datacenters and remote/branch office environments, the AV 3000 series KVM over IP switch provides consolidated, streamlined access to server resources. Centralize the management of the switches with DSView 4 Management software.


Powerful User Access Control

  • Grant access to specified users or implement LDAP directory authentication
  • Limit KVM access to specific targets on the switch Enable smart card or CAC readers to support two factor authentication
  • Streamlined Management

  • Local Port Access - Support for virtual media, USB keyboards and mice
  • Single Solution that supports USB, PS/2, Sun and serial targets
  • Advanced, graphical On-Screen Display eases system onfiguration and server selection
  • Space-Saving

    • CAT-5, thin cabling saves space in the rack and allows up to a 30 meter distance between the server and the switch


    • Local or Remote Access – The AV 3000 KVM over IP switch portfolio provides integrated local or remote KVM over IP management capability – right out of the box
    • Virtual Media Support - Share a directly connected USB storage device to all servers connected to a KVM switch (a DSAVIQ-USB2 module is required for virtual media support)
    • Common Access Card (CAC)/Smart Card Support - Enhances security to meet US government regulation HSPD12 which is required for ensuring secure login to government systems (an AVRIQ-VMC module is required for CAC support)
    • Server/Computer Access - Manage PS/2, USB, Sun or serial devices Flash Upgrade - Fast and easy upgrades to firmware switches and server interface modules
    • Easy to Use - Configure your system name and select your servers from the convenient OSD
    • Standards-Based - Uses standard CAT-5 cables
    • OS Independent - BIOS-level access ensures connection to the attached servers regardless of the health or type of operating system
    • Compatible with the Avocent DSView 4 Management software for a centralized and secure management of IT assets

    Model NumberAV3108-001
    Product Specifications
    DESCRIPTION1x8 Cat-5 switch with USB, OSCAR™ graphical user interface OSD, virtual media and CAC support
    Form Factor1U rack mount
  • 1.72 inches
  • 4.37cm
  • 1U
  • Width:
  • 17 inches
  • 43.2 cm
  • Depth:
  • 6.5 inches
  • 16.5 cm
  • Weight4.2 lbs. (1.9 kg)
    Device Connectors
  • 8 ports for servers or serial devices
  • 4 USB 2.0 ports
  • Remote Access1 remote KVM over IP user
    10/100 Mbps Ethernet port
    Local Access
  • 1 local port
  • 1 ACI port for tiering to another
    AutoView switch
  • VM / CAC Support
  • Virtual Media support over USB
  • Common Access Card (CAC) capability for smart cards
  • 128-bit SSL, AES, DES and 3DES encryption
  • Features Included
  • Agentless control and access for 1 remote user
  • LDAP authentication
  • Single-stack IPv4 or IPv6 access
  • Flash-upgradeable firmware AV KVM Switch and AVRIQ
  • Video SupportLocal VGA connection. Supports VGA, DisplayPort, HDMI, or DVI targets
    16:9 widescreen, up to 1680 x 1050,br>4:3 standard, up to 1600 x 1200
    Management SoftwareOSCAR™ On-Screen Display for local access
    Web User Interface
    Compatible with Avocent DSViewTM management software
    Power Supply SpecificationsConnector:
  • IEC C14
  • Type:
  • Internal
  • Power:
  • 18W
  • Heat dissipation:
  • 47 BTU/hr
  • AC input range:
  • 100 - 240 VAC
  • AC frequency:
  • 50/60 Hz auto-sensing
  • AC input current rating:
  • 5 A
  • AC input power (maximum):
  • 20W
  • EnvironmentalOperating: 32 to 122 degrees Fahrenheit (0 to 50 degrees Celsius)
    Non-operating: -4 to 158 degrees Fahrenheit (-20 to 70 degrees Celsius)
    Airflow is from non-port side (Front) to port side (Back)
    Supported Server Interface AdaptersMulti-platform support: PS/2 and USB. Also support for Avocent PS/2, PS2M, USB, Sun, USB2, VMC modules; Dell PS/2, USB, USB2-VM, USB2-VM+CAC SIPs
    Approved AgenciesUL, FCC Class A, cUL, ICES Class A, CE, EAC, VCCI Class A, KCC Class A, C-Tick, BSMI

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: AV3108

    Weight: 4.2 lb

    Warranty: 2 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    2 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
