Cisco Aironet AIR-ANT2513P4M-N Four-Port Dual-Band Polarization-Diverse 2.4-2.5 / 5.15-5.925 GHz Antenna 13 dBi - Brand New
Cisco Aironet Four-Port Dual-Band Polarization-Diverse Antenna
This document describes the AIR-ANT2513P4M-N antenna and provides electrical specifications and mounting instructions. The antenna is a four-port polarization-diverse patch array that operates over the 2.4-GHz and 5-GHz Wi-Fi bands. It ships with an articulating mount for use on flat surfaces and masts and is adjustable in both the horizontal and vertical planes. The radome is paintable using commonly available non-conductive spray paints, such as Krylon or Rust-Oleum. The antenna is designed for use in indoor and outdoor environments with Cisco Aironet 3702P and 1570 series access points.
System Requirements
This antenna is designed for use with Cisco Aironet 3702P and 1570 series access points. The antenna can be mounted on a wall, a ceiling, or a pole with a maximum diameter of 5 inches (12.7 cm).
| Cisco Aironet Four-Port Dual-Band Polarization-Diverse Antenna | |
|---|---|
| Model Part# | AIR-ANT2513P4M-N |
| Technical Specifications | |
| Antenna Type | Dual-Band Polarization Diverse Patch Array |
| Operating Frequency Ranges | 2.4-2.5 GHz 5.15-5.925 GHz |
| Nominal Input Impedance | 2.4-2.5 GHz : 50 Ohms 5.15-5.925 GHz: 50 Ohms |
| VSWR | 2.4-2.5 GHz : |
| Peak Gain | 2.4-2.5 GHz : 13 dBi 5.15-5.925 GHz: 13 dBi |
| Polarization (Ports A & C) | 2.4-2.5 GHz : Vertical 5.15-5.925 GHz: Vertical |
| Polarization (Ports B & D) | 2.4-2.5 GHz : Horizontal 5.15-5.925 GHz: Horizontal |
| Nominal Elevation Plane 3-dB Beamwidth | 2.4-2.5 GHz : 33 Degrees 5.15-5.925 GHz: 27 Degrees |
| Nominal Azimuth Plane 3-dB Beamwidth | 2.4-2.5 GHz : 31 Degrees 5.15-5.925 GHz: 31 Degrees |
| V-Pol Maximum Sidelobe Level | 2.4-2.5 GHz : -15 dBc 5.15-5.925 GHz: -12 dBc |
| H-Pol Maximum Sidelobe Level | 2.4-2.5 GHz : -10 dBc 5.15-5.925 GHz: -12 dBc |
| Front-to-Back Ratio | 2.4-2.5 GHz : > 30 dB 5.15-5.925 GHz: > 30 dB |
| Connector Type | N-Female Bulkhead |
| Length | 14.5 in. (36.8 cm) |
| Width | 20 in. (50.7 cm) |
| Height | 0.8 in. (2.11 cm) |
| Weight | 81.1 oz. (2.3 kg) |
| Water/Foreign Body Ingress | IP67 |
| Operational Wind | 100 MPH |
| Operating Temperature Range | -40° C to 85° C |
