Cisco CISCO2811 Integrated Services Router


DiscTech Item #: CIS-CISCO2811-RF-OE

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Interface Types: USB 1.1, Ethernet RJ45

Electrical Interface: Ethernet Fast - 100Mbps

On-Board Cache: 256MB

Bays/Ports/Slots: 2

U Height: 1U

Voltage: 110-240V Multi

Cisco CISCO2811 / 2811 2800 Series Integrated Services Router - 2 FE, 1NME, 4 HWIC, 2 PVDM Slots, 256MB DRAM, 64MB Flash - Refurbished

Cisco CISCO2811 / 2811 2800 Series Integrated Services Router - 2 FE, 1NME, 4 HWIC, 2 PVDM Slots, 256MB DRAM, 64MB Flash - Refurbished

Cisco Systems ®, Inc. redefined best-in-class enterprise and small- to- midsize business routing with a new line of integrated services routers that are optimized for the secure, wire-speed delivery of concurrent data, voice, video, and wireless services. Founded on 20 years of leadership and innovation, the Cisco ® 2800 Series of integrated services routers (refer to Figure 1) intelligently embed data, security, voice, and wireless services into a single, resilient system for fast, scalable delivery of mission-critical business applications. The unique integrated systems architecture of the Cisco 2800 Series delivers maximum business agility and investment protection.

  • Default: 256 MB
  • Maximum: 768 MB
  • Compact Flash
  • Default: 64 MB
  • Maximum: 256 MB
  • Fixed USB 1.1 Ports2
    Onboard LAN Ports2-10/100
    Onboard AIM (Internal) Slot2
    Interface Card Slots4 slots, each slot can support HWIC, WIC, VIC, or VWIC type modules
    Network-Module Slot1 slot, supports NM and NME type modules
    Extension Voice Module Slot0
    PVDM (DSP) Slots on Motherboard2
    Integrated Hardware-Based EncryptionYes
    VPN Hardware Acceleration (on Motherboard)DES, 3DES, AES 128, AES 192, and AES 256
    Optional Integrated In-Line Power (PoE)Yes, requires AC-IP power supply
    Console Port (up to 115.2 kbps)1
    Auxiliary Port (up to 115.2 kbps)1
    Minimum Cisco IOS Software Release12.3(8)T
    Rack MountableYes, 19- and 23-in. options
    Wall MountableYes
    Power Requirements
    AC Input Voltage100 to 240 VAC, autoranging
    AC Input Frequency47-63 Hz
    AC Input Current2A (110V) 1A (230V)
    AC Input Surge Current50A maximum, one cycle
    AC-IP Maximum In-Line Power Distribution160W
    AC-IP Input Current4A (110V) 2A (230V)
    AC-IP Input Surge Current50A maximum, one cycle
    DC Input Voltage24 to 60 VDC, autoranging positive or negative
    DC Input Current
  • 8A (24V)
  • 3A (60V)
  • Startup current 50A<10 ms
  • Typical Power Dissipation (No Modules)32W (109 BTU/hr)
    Power Dissipation-AC without IP Phone Support170W (580 BTU/hr)
    Power Dissipation-AC with IP Phone Support-System Only210W (717 BTU/hr)
    Power Dissipation-AC with IP Phone Support-IP Phones160W (546 BTU/hr)
    Power Dissipation-DC180W (614 BTU/hr)
    RPSExternal only, connector for RPS provided by default
    Recommended RPS UnitCisco RPS-2300 Redundant Power System
    Environmental Specifications
    Operating Temperature32° to 104°F (0° to 40°C)
    Non-Operating Temperature-40° to 158°F (-40° to 70°C)
    Maximum Operating Temperature at Altitude
  • 40°C @ sea level
  • 40°C @ 6,000 ft (1800 m)
  • 30°C @ 13,000 ft (4000 m)
  • 27.2°C @ 15,000 ft (4600 m)
    Note: Derate 1.4°C per 1,000 ft above 6,000 ft
  • Operating Humidity5 to 85%RH, non-condensing
    Dimensions (H x W x D)
  • 1.75 x 17.25 x 16.4 in.
  • (44.5 x 438.2 x 416.6 mm)
  • Rack Height1 rack unit (1RU)
    Weight (Fully Configured)14 lb (6.4 kg)
    Noise Level (Min/Max)
  • 47 dBA for normal operating temperature (<90°F/32.2°C)
  • 57 dBA (@ maximum fan speed)

  • Click here to view the manufacturer's item description/brochure

    Alternate MPNs: 2811

    Weight: 17 lb

    Warranty: 1 Year DiscTech
