DELL 540-BBVK / W79Y8 Broadcom 57414 25GB SFP28 Ethernet PCIe Network Interface Card
- Brand NewCondition Levels Explained
The product is brand new.
- In Stock:12Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Interface Types: | SFP |
Description
DELL 540-BBVK / W79Y8 Broadcom 57414 25GB SFP28 Ethernet PCIe Network Interface Card - Brand New
Dell now offers Broadcom® 540-BBVK / 540-BBVK / W79Y8 / 57414 Dual-Port 10/25GbE SFP28 RNDC Network Interface Card (NIC) for Select Dell® PowerEdge® rack servers and PowerVault® storage arrays. It leverages Broadcom's long-standing industry leadership in Optical Fiber, providing the highest levels of performance, efficiency, and scalability for the enterprise data center
Designed for today's enterprise, the Broadcom 57414-based NIC adapter is the ideal solution for multicore servers, delivering full line-rate throughput across all ports. The adapter utilizes Broadcom's dual-port BCM57414 integrated controller to deliver lower power consumption and Energy Efficient Ethernet™ (EEE), reducing IT operation costs.
Increasing application workloads are placing greater demands on enterprise networks, and the Broadcom 57414-based Dual-port 10/25GbE NIC is the solution of choice for such environments, providing a reliable, high-performance, energy-efficient 10/25GbE connectivity solution.
Features
- Dual-port GbE NIC for select Dell PowerEdge rack servers and PowerVault storage arrays
- Dual-port pluggable media interface, which may be equipped with 25G SFP28 or 10G SFP+ optical transceiver or with copper direct-attach cable
- Fully compliant with the SFF-8402 standard
- Features a compact space-saving design
- Ideal for high-performance network applications
- SR-IOV with up to 128 VFs
- Function Level Reset (FLR) support
- TruFlow™ flow processing engine
- Virtual Network Termination–VXLAN, NVGRE, Geneve, GRE encap/decap
- vSwitch acceleration
- Tunnel-aware stateless offloads
- DCB support: PFC, ETS, QCN, DCBx
- RDMA over converged Ethernet (RoCE)
- SMBus 2.0
- MCTP over SMBus
- Jumbo frames up to 9 KB
- Advanced Congestion Avoidance
- Multiqueue, NetQueue, and VMQ
- IPv4 and IPv6 offloads
- TCP, UDP, and IP checksum offloads
- Large Send Offload (LSO)
- Large Receive Offload (LRO)
- TCP Segmentation Offload (TSO)
- Receive-side Scaling (RSS)
- Transmit-side Scaling (TSS)
- VLAN insertion/removal
- Interrupt coalescing
- Network boot-PXE, UEFI
- iSCSI boot
- MSI and MSI-X
- Broadcom Advanced Control Suite (BACS) management application and integration into Dell's embedded management framework (iDRAC7 and Lifecycle Controller)
Applications
Dual-Port 25 Gb/s Ethernet Network Interface Card for Data Centers or Cloud Computing.
Alternate Part Numbers: JJ4YH 0JJ4YH 9XY73 09XY73
Compatibility:
This Dell Broadcom network adapter is compatible with the following Dell / EMC PowerEdge servers and PowerVault storage arrays ...
- PowerEdge R640
- PowerEdge R740
- PowerEdge R740XD
- PowerEdge R7425
- PowerEdge R840
- PowerEdge R940
- PowerEdge R940xa
- PowerVault NX3240
- PowerVault NX3340
Specifications
| General - Dell 540-BBUS / W79Y8 / 0W79Y8 |
| Mezzanine Daughter Board |
| 2 x 25Gb Ethernet - SFP28 Ports |
| For Select Dell Rack Servers and PowerVault Storage Arrays |
| PCIe x8 Server Adapter |
| Data transfer rate per port 2500 Mbps |
| MAC controller BCM57414 |
| Connector 2x 25 Gigabit SFP28 |
| Advanced Features and Standards |
| Fully compliant with the SFF-8402 standard |
| SR-IOV with up to 128 VFs |
| Function Level Reset (FLR) support |
| TruFlow™ flow processing engine |
| Virtual Network Termination–VXLAN, NVGRE, Geneve, GRE encap/decap |
| vSwitch acceleration |
| Tunnel-aware stateless offloads |
| DCB support: PFC, ETS, QCN, DCBx |
| RDMA over converged Ethernet (RoCE) |
| SMBus 2.0 |
| MCTP over SMBus |
| PCIe-based UART and KCS |
| Jumbo frames up to 9 KB |
| Advanced Congestion Avoidance |
| Multiqueue, NetQueue, and VMQ |
| IPv4 and IPv6 offloads |
| TCP, UDP, and IP checksum offloads |
| Large Send Offload (LSO) |
| Large Receive Offload (LRO) |
| TCP Segmentation Offload (TSO) |
| Receive-side Scaling (RSS) |
| Transmit-side Scaling (TSS) |
| VLAN insertion/removal |
| Interrupt coalescing |
| Network boot-PXE, UEFI |
| iSCSI boot |
| MSI and MSI-X |
Alternate MPNs: W79Y8 0W79Y8
Weight: 2 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
