Seagate Savvio 10K.5 ST9900605SS SAS SED Hard Drive
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 900GB |
| Speed: | 10K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
Dell Enterprise plus P4DC3 / Seagate Savvio 10K.5 ST9900605SS 900GB 10K 6Gbps SFF SED Encryption/FIPS 9XS066-257 SAS Hard Drive - New Pull OEM
Ideal for NAS, SAN and DAS external enterprise storage solutions.
This fifth-generation Savvio 10K.5 drive provides the highest capacity and best reliability available in a small form factor, 10K-RPM enterprise hard drive. This drive enables 3.5-inch to 2.5-inch form factor transition and widespread market adoption of 2.5-inch-based external storage solutions for enterprise OEMs, system designers and end-user organizations. Self-Encrypting Drives (SED) and FIPS 140-2 Validated™ SED security options are available to help you protect your data.
Key Features and Benefits
- Delivers the highest-capacity in a 2.5-inch, 10K-RPM hard drive (up to 900GB) to manage more data without increasing the number of drives
- First SFF drive to offer four capacity points on a single platform
- Industry-leading 0.44% AFR for field-proven reliability
- Improves performance for faster data storage and access
- Reduces power consumption and enables green IT initiatives
- PowerChoice™ technology for T10-compliant power management enables IT organizations to tailor systems for performance and power consumption
- Reduces system design, qualification and inventory costs for OEMs
- Enables data centers to better manage hard drive transitions
- Protection Information protects against inadvertent data change¹
- Seagate Unified Storage architecture reduces system complexity and operating costs by converging disparate interfaces, form factors and security standards
Compatibility
This drive is compatible with any server that accepts small form factor (SFF) SAS hard drives
Specifications
| Specifications | |
|---|---|
| Model Number | ST9900605SS |
| Interface | 6-Gb/s SAS |
| Cache | 64MB |
| Capacity | 900GB |
| Areal density (avg) | 506Gb/in2 |
| Guaranteed Sectors | 1,758,174,768 |
| PHYSICAL | |
| Height (maximum) | 15.00mm (0.591 in) |
| Width (maximum) | 70.10mm (2.760 in) |
| Length (maximum) | 100.45mm (3.955 in) |
| Weight (typical) | 205g (.451 lb) |
| PERFORMANCE | |
| Spin Speed (RPM) | 10,000 RPM |
| Sustained data transfer rate | 168MB/s |
| Average latency | 3.0ms |
| Random read seek time | 3.7ms |
| Random write seek time | 4.1ms |
| I/O data transfer rate | 600MB/s |
| Unrecoverable read errors | 1 in 10^16 |
| RELIABILITY | |
| MTBF | 2,000,000 hours |
| Annual Failure Rate | 0.44% |
| POWER | |
| 12V start max current | 1.00A |
| 5V start max current | 0.63A |
| Average idle power | 4.42W |
| ENVIRONMENT | |
| Ambient Temperature | |
| Operating | 5°–55°C |
| Nonoperating | -40°–70°C |
| Maximum operating temperature change | 20°C per hour |
| Maximum nonoperating temperature change | 20°C per hour |
| Shock | |
| Operating Shock (max) | 40 Gs for 11ms |
| Nonoperating Shock (max) | 400 Gs for 2ms |
| ACOUSTICS | |
| Acoustics (Idle Volume) | 3.0 bels |
| Features | |
| Storage Type | HDD |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: P4DC3 0P4DC3 9XS066-257
Weight: 1 lb
Warranty: 1 Year DiscTech
Condition
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
Warranty
1 Year DiscTech Warranty
