Dell Enterprise 00X3Y / 609Y5 / Seagate Constellation.2 ST9500620NS 500GB 7.2K SFF SATA Hard Drive

Seagate Part #/MPN: ST9500620NS

DiscTech Item #: SGT-ST9500620NS-BN-OE-DEL

$69.00
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:1 Year DiscTech
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

  • In Stock:94Need more?
    Stock Levels

    This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.

Back
$69.00

Enterprise Grade

Capacity: 500GB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 115

Average Seek Time: 7.5 / 8.5

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 64MB

Dell Enterprise 00X3Y / 609Y5 / Seagate Constellation.2 ST9500620NS 500GB 7.2K SFF SATA Hard Drive - Brand New OEM

The Constellation 7200 hard drive enables manageable nearline storage solutions in 2.5" chassis — either direct attach or in a tiered storage environment — at the lowest power usage without compromising performance or reliability. Constellation 500GB SATA drives deliver cost-effective, eco-friendly nearline storage.

Key Features and Benefits

  • Industry’s first 2.5-inch 500GB capacity-optimized drive for dense, space-constrained data centers allows you to store twice as much data in the same footprint.
  • Build highly efficient bulk storage solutions while lowering your power consumption costs
  • Designed for robust 24x7 operation with a 1.4M hour mean-time-between-failure (MTBF) rating
  • Best-in-class rotational vibration tolerance ensures unrivaled performance in high spindle-density applications, and multi-drive firmware maximizes system availability
  • Choose from 6Gb/s SAS with improved data integrity, scalability and fastest data access or SATA 6Gb/s for economical 7200-RPM performance
  • TCG- compliant, Self-Encrypting Drive (SED) security option cuts IT drive retirement expenses while securely protecting data*

DPN: 00X3Y 609Y5 0609Y5

Compatibility:

This drive is compatible with any of our SATA drive trays and any of our SATA controllers.

Drive specification

ST9500620NS

Formatted Gbytes (512 bytes/sector)

500

Bytes per sector

512

Spindle speed (RPM)

7,200

I/O data transfer rate (MBps)

600

Cache buffer

64

Interface Type

Serial ATA-300

Average latency

4.16 ms

Seek time (read / write) ms

7.5 / 8.5

Dimensions (HxLxW) mm

14.8 / 100.5 / 70

Weight

183g

Operating Shock (Read)

70G, 2ms

Non-operating Shock

400G, 2ms

Temperature - Operating

5C -55C

Temperature - Non-operating

-40C - 70C

Current Requirements 12VDC (Read/Write, Idle)

3.5w / 2.6w

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 00X3Y 000X3Y 9RZ164-136 609Y5 0609Y5
