Dell 3JY18 / Micron 5200 ECO Series MTFDDAK7T6TDC-1AT1ZABYY 7680GB 2.5in 6Gbps 3D TLC SATA SSD

Micron Part #/MPN: MTFDDAK7T6TDC-1AT1ZABDB

DiscTech Item #: MIC-MTFDDAK7T6TDC-1AT1ZABDB-BN-OE-DEG


$999.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$999.00

Enterprise Grade

Capacity: 7.68TB

Speed: Solid State Memory

Interface Types: SATA

Form Factor: 2.5inx7mm Fits All laptops

Sector Size: 512 / 512e

Sustained Throughput: 540/520

Average Seek Time: 40 µs

Electrical Interface: SATA 600 - 6.0Gbps

SSD Type: TLC

SSD Endurance DWPD: Enterprise Read Intensive

Dell 3JY18 / Micron 5200 ECO Series MTFDDAK7T6TDC-1AT1ZABDB 7.68 TB 7680GB 2.5in 6Gbps 3D TLC SATA SSD - Brand New OEM

Dell 3JY18 / Micron 5200 ECO Series MTFDDAK7T6TDC-1AT1ZABDB 7.68 TB 7680GB 2.5in 6Gbps 3D TLC SATA SSD - Brand New OEM

Dell PN / DPN : 3JY18 03JY18

Micron’s 5200 solid state drive (SSD) uses a single-chip controller with a SATA interface on the system side and four channels of Micron NAND Flash internally. Available in the 2.5-inch form factor, the SSD integrates easily in existing storage infrastructures.

The SSD is designed to use the SATA interface efficiently during both READs and WRITEs while delivering bandwidth-focused performance. SSD technology enables enhanced boot times, faster application load times, reduced power consumption and extended reliability.


Compatibility:

This drive is compatible with laptops that accept 2.5" x 7mm SFF SATA drives or Servers that accepts SFF SATA

Micron 5200
Model NumberMTFDDAK7T6TDC-1AT1ZABDB
Technical Specification
BrandMicron
ManufacturerMicron Enterprise SSD
Model5200
Capacity7680GB
Form Factor2.5in (6.4cm)
Device TypeSolid State Drive
InterfaceSATA 6Gb/s
Serial ATA-600
Dimensions (Depth x Height x Width)4in x 0.3in x 2.7in
Weight1.98oz
Humidity Range Operating5 - 95% (non-condensing)
Max Operating Temperature158°F
Min Operating Temperature32°F
4KB Random Read95000 IOPS
4KB Random Write32000 IOPS
Average Latency40 µs
Bytes per Sector512
Compliant StandardsS.M.A.R.T.
Data Transfer Rate600 MBps
Hard Drive TypeInternal hard drive
Internal Data Rate540 MBps
Internal Data Rate (Write)520 MBps
Manufacturing Process16nm
NAND Flash Memory Type3D Triple-level cell (TLC)
Non-Recoverable Errors/td>1 per 10^15
Compliant Standards
  • AS/NZS CISPR 32 Class B
  • BSMI CNS 13438
  • EN 55032 Class B
  • EN 60950
  • FCC CFR47 Part 15 B
  • ICES-003 Class B
  • IEC 60950
  • KN32
  • KN35
  • NMB-3 Class B
  • RoHS
  • TUV
  • UL 60950-1 Second Edition
  • VCCI Class B
  • WEEE 2012/19/EC
  • MTBF2,00,000 hours
    Features
  • Adaptive thermal monitoring
  • ATA security
  • DEVSLP SATA low power mode
  • Dynamic and Static Wear Leveling
  • Dynamic write acceleration
  • Microsoft eDrive compatible
  • Secure Erase function
  • ROHS Compliant

    Alternate MPNs: 3JY18 03JY18

    Weight: 1 lb

    Warranty: 1 Year DiscTech

    Brand New

    Condition Levels Explained

    The product is brand new.

    1 Year DiscTech Warranty

    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty
