Dell 4TRHM / KIOXIA KPM7XVUG1T60 1.6TB 2.5inch 24Gbps Mixed Use TLC SAS SSD 3-DWPD PM7-V Series SAS-4
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 1.6TB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| SSD Endurance DWPD: | Enterprise Mixed Use / MU |
| Electrical Interface: | SAS-4 24Gbps |
Description
Dell 4TRHM / KIOXIA KPM7XVUG1T60 1.6TB 2.5inch 24Gbps Mixed Use TLC SAS SSD 3-DWPD PM7-V Series SAS-4- Brand New
Dell 4TRHM / KIOXIA KPM7XVUG1T60 1.6TB 2.5inch 24Gbps Mixed Use TLC SAS SSD 3-DWPD PM7-V Series SAS-4- Brand New
PM7-V Series - Enterprise Mixed Use SAS SSD
KIOXIA PM7-V Series 24G SAS Enterprise SSD is optimized for mixed use applications, including relational database, streaming media, data warehousing and web services. The series is designed to deliver balanced levels of performance, reliability, capacity and endurance for mixed use and read intensive environments. Featuring KIOXIA 112-layer BiCS FLASH™ 3D flash memory, this 7th generation enterprise SAS SSD PM7-V offers 3 DWPD (Drive Writes Per Day) with capacities up to 12.8 TB.
Key Features:
- 24.0 Gbit/s SAS interface with single/dual port
- Capacities from 1.6TB to 12.8TB
- Up to 720K random read IOPS (4 KiB) in dual-port mode
- 2.5 inch form factor, 15 mm thickness
- 3 DWPD with 100 % Random Write Workload
- Power loss protection and end-to-end data protection, including T10 DIF Pin-3 power disable support
- Security options: SIE, SED, FIPS SED
Key Applications
- Web Servers
- Data Warehousing
- Streaming Media
DPN: 4TRHM , 04TRHM
Compatibility:
This drive is compatible with any server that accepts 2.5in x 15mm (SFF) SAS drives.
Specifications
| Enterprise Read Intensive SSD | |
|---|---|
| Basic Specifications | |
| Reliability | |
| Power Requirements | |
| Dimensions | |
| Enviromental | |
| Model Number | KPM7XVUG1T60 |
| Interface | SAS-4.0 |
| Interface Speed | 22.5 Gbit/s , 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Memory Type | BiCS FLASH TLC |
| Formatted Capacity | 1.6TB |
| Sustained 1284KiB Sequential Read | 3,400 MiB/s |
| Sustained 128KiB Sequential Write | 3,400 MiB/s |
| Sustained 4KiB Random Read | 720,000 IOPS |
| Sustained 4KiB Random Write (in dual port mode) | 320,000 IOPS |
| MTTF | 2,500,000 hours |
| DWPD | 3 |
| Supply Voltage | 5 V ±7 % , 12 V ±7 % |
| Power Consumption (Operating) | 5.0W Typ. |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 69.85 ±0.25 mm |
| Length | 100.45 mm Max. |
| Weight | 130 g Max. |
| Temperature (Operating) | 0 to 60 °C |
| Relative Humidity ( Operating ) | 5 to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s {2.17 Grms} (100 to 800 Hz) |
| Shock (Operating) | 9.8 km/s {1,000 G} (0.5 msec) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 4TRHM 04TRHM
Weight: 0.7 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
