Toshiba Part #/MPN: AL15SEB060NY
DiscTech Item #: TOS-AL15SEB060NY-RF-OE-DEL
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Inventory Is InboundStock Levels
This item is currently on order with our supplier and is expected to arrive soon.
Enterprise Grade
Capacity: 600GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Average Seek Time: 3.7 / 4.1
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 64MB
Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620
Dell 4WX8Y / Toshiba AL15SEB060NY 600GB 12Gbps 10K 2.5" SFF Enterprise SAS Hard Drive - Refurbished OEM
Dell 4WX8Y / Toshiba AL15SEB060NY 600GB 12Gbps 10K 2.5" SFF Enterprise SAS Hard Drive - Refurbished OEM
The 12.0 Gbit/s SAS interface AL15SEB Series Enterprise Performance HDDs provide up to 2.4 TB capacity and 10,500rpm performance with Enterprise-class reliability. Engineered for mission critical IT operations, including database servers and hybrid storage platforms, AL15SE Series provides a range of models including 512 native (512n), or emulated 512 (512e) or 4K native(4Kn) sector length technologies for suitable application and operating system compatibility. Toshiba Persistent Write Cache technology protects against data loss in the event of unexpected power loss, and helps maintain suitable performance and data reliability for high-duty cycle Mission Critical environments.
Key Features
- 2400, 1800, 1200, 900 and 600 GB Capacity (Advanced Format sector technology models)
- 1200, 900, 600, 300GB (512n sector technology models)
- Space Efficient, Power Saving 2.5-inch Form Factor
- 12.0 Gbit/s SAS Interface for Better Performance
- 10,500 rpm Performance
- Industry Leading Average Latency (2.86ms)
- 24/7 Mission Critical Workload Performance and Data Reliability
- 512n sector length support in all capacities for optimum legacy application compatibility
- Toshiba Persistent Write Cache Technology
- Sanitize Instant Erase (SIE) Option
Applications
- Tier 1 Mission-Critical Servers and RAID Storage
- Tier 1 Hybrid Storage platforms Servers hosting transaction-based applications
- Rack-Optimized Data Centers Content Serving with low-latency requirements
- Software-defined and Converged Storage architecture
- Mission-Critical Server Boot and Logging
Compatibility:
This drive is compatible with any server that accepts 2.5" x 15mm (SFF) SAS hard drives.
Specifications | |
---|---|
Model Number | AL15SEB060NY |
Dell Part Number | 4WX8Y |
Drive Capacity | 600GB |
Drive Interface | SAS 2.0 |
RoHS Compliant | Yes |
Transfer Rate to Host | 12 Gb/sec |
Performance | |
Track-to-track Seek | 0.2ms typ. (Read), 22ms typ. (Write) |
Average Seek Time | 3.7ms typ. (Read), 4.1 ms typ. (Write) |
Rotational Speed | 10,500 RPM |
Average Latency | 2.8 ms |
Buffer Size | 128MB |
Power Requirements | |
Voltage | 5V (+/- 5%), 12V (+/- 5%) |
Spin up (start) Power | 12V (=/-5%) @ 1.65A (peak) 3.0A (peak < 100us) 1.5V (+/-5%) @ 1.1A (peak) |
Power Idle (Ready) | 4.0 watts (max.) |
Physical Size | |
Dimensions (W) x (D) x (H) | 69.85 mm (2.75”) x 100.45 mm (3.95”) x 15 mm (0.59”) |
Weight | 220 g, or less |
Environmental | |
Temp - Operating - Non-Operating | 5° to 55°C (41° to 131°F) -40° to 70°C (-40° to 158°F) |
Humidity - Operating - Non-Operating | 5% to 95% RH 5% to 95% RH |
Vibration - Operating - Non-Operating | (0.6mm) 5 to 20 Hz / 9.8 m/s² (1.0G) 20 to 300 Hz (3.1mm) 5 to 20 Hz / 49 m/s² (5.0G) 20 to 300 Hz |
Shock - Operating - Non-Operating | 980 m/s2 (100G) 1ms 3,920 m/s2 (400G) 1ms |
Altitude - Operating - Non-Operating | -1,000 to 10,000 ft -1,000 to 40,000 ft |
Acoustics | |
Acoustics (Ready) | 30dB |
Reliability | |
Mean Time Between Failures (MTBF) | 2,000,000 hours |
Component Life | 5 years POH |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 4WX8Y 04WX8Y
Weight: 1 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
