Dell Compellent 5H3XX / HGST Ultrastar C10K1800 HUC101818CS4204 0B31867 1.8TB 2.5" 12Gbps 10K Enterprise SAS HDD

Hitachi Part #/MPN: HUC101818CS4204

DiscTech Item #: HIT-HUC101818CS4204-RF-OE-DEC


Enterprise Grade

Capacity: 1.8TB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 146 to 247

Average Seek Time: 3.3-3.7 / 3.8-4.4

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

On-Board Cache: 128MB

Dell Compellent 5H3XX / HGST Ultrastar C10K1800 HUC101818CS4204 0B31867 1.8TB 2.5" 12Gbps 10K Enterprise SAS HDD - Refurbished

Dell Compellent 5H3XX / HGST Ultrastar C10K1800 HUC101818CS4204 0B31867 1.8TB / 1800GB 2.5" / SFF 12.0Gb/s 10K RPM Enterprise SAS / Serial Attached SCSI HDD / Hard Disk Drive - Refurbished

Alt DPN: 05H3XX

Ultrastar® C10K1800
2.5-Inch SFF Enterprise 10K RPM Hard Disk Drives

Big Capacity and Performance in a Small Package
HGST delivers best-in-class capacity and performance in one small form factor hard drive. The Ultrastar® C10K1800 is a 10K RPM enterprise-class HDD that stores up to 1.8TB of data, 50% more capacity than prior generations, plus delivers best-in-class active and idle power efficiency, enabling next generation data centers to keep pace with digital data growth and improve space and power efficiencies. Data center architects can also leverage best-in-class performance on the C10K1800, achieving up to 2.5X better random write performance and 23% faster sequential performance over prior generation 2.5-inch SFF 10K RPM HDDs for demanding 24x7 enterprise workloads.

Technology Innovation
Ultrastar C10K1800 delivers unmatched performance thanks to several HGST technology innovations including media cache architecture,the industry’s fastest 12Gb/s Serial Attached SCSI (SAS) interface and advanced format options. HGST's media cache architecture is a disk-based caching technology, which provides a large non-volatile cache on the media resulting in improved reliability and data integrity during unexpected power loss, as well as a significant improvement in write performance even at high workloads when compared to solutions with limited NAND or flash-based NVC. The C10K1800 is the industry’s first 10K RPM drive to leverage an industry-leading 12Gb/s SAS interface, enabling very high transfer rates between host and drive. Advanced format models enable the industry’s highest 10K RPM capacity at 1.8TB with 4K native and 512 emulation to support new systems, and also offers 512 native format models to support legacy systems.

Enterprise Security and Reliability
The Ultrastar C10K1800 offers the broadest range of encryption and security options available on SAS HDDs from HGST, including Trusted Computing Group (TCG) enterprise SSC-compliant Self-Encrypting Drives (SED) which provide data protection without any performance loss, and TCG with FIPS (Federal Information Processing Standard) 140-2 certification, which adds and tamper evidence protection for the most stringent regulatory data security compliance requirements. Instant Secure Erase (ISE) models enable fast, cost-effective and secure drive repurposing and retirement. C10K1800 extends the company’s long-standing tradition of reliability leadership with a 2M hours MTBF rating.


  • Industry-leading 1.8TB capacity in a 10K RPM HDD, 50% more than previous generations
  • Best-in-class performance
    • 2.5X faster random write
    • 23% faster sequential
  • Advance format (4KN and 512e) and 512n models
  • 6Gb/s SAS moves more data quickly & reliably
  • 128MB cache buffer manages data efficiency
  • Advanced Power Management optimizes power consumption
  • Best-in-class power efficiency
  • 2M hours MTBF rating
  • Security & encryption models including ISE, TCG-SED & FIPS 140-2 certified TCG-SED


  • Tier 1 enterprise-class, high-performance servers in data centers processing hot and warm data
  • Traditional mission-critical enterprise-class servers and storage
  • HPC, databases, OLTP, and BP applications requiring high reliability and 24x7 availability
  • Enterprise-class data security environments requiring increased security & easy drive retirement
  • Power- and space-constrained, mission-critical environments


This drive is compatible with any server that accepts 2.5"x15mm (SFF) SAS hard drives.

Model NumberHUC101818CS4204
Part Number0B31867
InterfaceSAS 12Gbps
Capacity (GB)1.8
Sector size (variable, bytes/sector)4096-Byte (512e)
Recording zones40
Data heads (physical)8
Data disks4
Max. areal density (Gbits/sq. in.)620
Data buffer (MB)128
Rotational speed (RPM)10,520
Latency average (ms)2.85
Interface transfer rate (MB/s, max)1200
Sustained transfer rate (MB/s, typical)146 to 247
Seek time (read/write, ms, typical range)3.3-3.7 / 3.8-4.4
Error rate (non-recoverable, bits read)1 in 1016
MTBF (M hours)2.0
Availability (hrs/day x days/wk)24x7
Idle (Bels)3.4
Requirement+5 VDC (+/-5%)
+12 VDC (+/-5%)
Operating, (W, typical)7.4
Idle (W)5.1
Idle efficiency (W/GB)0.003 (1.8TB)
Physical size
z-height (mm)15
Dimensions (width x depth, mm)70.1 x 100.45
Weight (g, max)227
Environmental (operating)
Ambient temperature5o to 55o C
Shock (half-sine wave 2ms, read operation)60G
Vibration, random, no errors (G RMS 5 to 500 Hz)0.4, all axes
Environmental (non-operating)
Ambient temperature-40o to 70o C
Shock (half-sine wave, 2ms, read operation)300G
Vibration, random (G RMS, 5 to 500 Hz)1.5, all axes

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 5H3XX 05H3XX

Weight: 1 lb

Warranty: 1 Year DiscTech


Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
