Dell Compellent G860Y / HGST HUSMH8020BSS200 200GB 2.5" WI SAS SSD

Dell Equallogic Compellent Part #/MPN: HUSMH8020BSS200

DiscTech Item #: HIT-HUSMH8020BSS200-BN-OE-DEC


Enterprise Grade

Capacity: 200GB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Encryption/SED Supported

Sector Size: 512 / 512e

Sustained Throughput: 1100/765

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps


SSD Endurance DWPD: Enterprise Write Intensive

Compatible Systems: Dell Compellent SCv2000 SCv2020 SC200 SC120 SC100

Dell Compellent G860Y / HGST HUSMH8020BSS200 200GB 2.5" WI SAS SSD - Brand New

Dell Compellent G860Y / HGST Ultrastar HUSMH8020BSS200 / 0B32016 200GB 3.5" / LFF / Large Form Factor 12Gb/s WI / Write Intensive 25 DWPD / Drive Writes Per Day Enterprise Plus SAS / Serial Attached SCSI SSD / Solid State Drive - Brand New

Ultrastar SSD800MMH.B

Maximum Performance, Reliability and Endurance
The Ultrastar SSD800MH.B delivers high sequential throughput, up to 1100MB/s read and 765MB/s write (12Gb/s SAS). It also delivers up to 130,000 read and 110,000 write IOPS, reaching speeds >100 times faster than HDDs and double the speed of current 6Gb/s SSDs, allowing rapid access to “hot” enterprise data for improved productivity and operational efficiency. The Ultrastar SSD800MH.B family offers significant value in terms of IOPS per Watt, while reducing total cost of ownership (TCO) through low power consumption, efficient cooling and reduced space requirements.
The Ultrastar SSD800MH.B family combines enterprise-grade MLC NAND Flash memory, advanced endurance management firmware and power loss data management techniques to extend reliability, endurance and sustained performance over the life of the SSD. The Ultrastar SSD800MH.B family achieves an extraordinary 0.35% annual failure rate (AFR) or 2.5 million hour meantime-between-failure (MTBF). The 800GB capacity model endures up to 36.5 Petabytes (PB) of random writes over the life of the drive—the equivalent of writing 20 Terabytes (TB) per day for five years

HGST Enterprise Storage ExperienceHGST leverages decades of proven enterprise storage expertise in Serial Attached SCSI (SAS) design, reliability, firmware, customer qualification and system integration to the Ultrastar® SSD800MH.B solid-state drive (SSD) family. The synergistic relationship between HGST’s throughput-enhancing SSDs and traditional HDDs provides cost effective, end-to-end enterprise-class storage solutions, delivering reliability, compatibility, capacity, cost and system performance. This combination makes HGST a leading SSD/HDD provider with the experience and technology needed to meet escalating reliability, endurance and performance in the most demanding enterprise environments.

HGST Quality and Service
HGST’s Ultrastar SSD800MH.B family extends the company’s long-standing tradition of performance and reliability leadership. A balanced combination of new and proven technologies enables high reliability and availability to customer data. HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of SSD/HDD solutions to satisfy today’s monumental computing needs.


  • MLC NAND Flash for ultra-high performance and endurance
  • Mainstream endurance 25DW/D for 5 years
  • Best IOPS/Watt for reduced TCO
  • 12Gb/s SAS interface for maximum throughput
  • Advanced power loss data management technology
  • Self-encrypting models conform to TCG’s Enterprise specification

Applications / Environments

  • Ultra-high performance tier-0 enterprise storage
  • Enterprise-class servers and high performance computing
  • Space and/or power constrained environments
  • Online Transaction Processing (OLTP)
  • Financial and e-commerce
  • Database analytics



This 3.5" SAS / SATA caddy is compatible with the following Dell SC Compellent systems supporting 3.5" hot swappable disks:

HGST Ultrastar® SSD800MH.B
Part Number0B32016
Model NumberHUSMH8020BSS200
InterfaceSAS 12Gb/s
Form factor2.5-inches
Flash memory technologyMulti Level Cell (MLC)
Sector size support512, 520, 528, 4K
Read throughput (max MB/s, sequential 64K)1100
Write throughput (max MB/s, sequential 64K)765
Read IOPS (max IOPS, random 4K)130,000
Write IOPS (max IOPS, random 4k)110,000
Error rate (non-recoverable, bits read)1 in 10^17
MTBF(M hours)2.5
Annual failure rate(AFR)0.35%
Availability (hrs/day x days/wk)24x7
Endurance (max PB, random write)9.1
Requirement+5 VDC (+/-5%)
+12 VDC (+/-10%)
Operating (W, typical)9.0 and 11.0
Idle, (W)2.2
Physical size
z-Height (mm)15.0
Dimensions (width x depth, mm)70.1 x 100.6
Weight (max, g)187
Environmental (operating)
Case temperature0° to 70° C
Shock (half-sine wave)1000G(0.5ms)
Vibration, random (G RMS)2.16, all axis (5 to 700 Hz)

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 0B32016 G860Y 0G860Y

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
